Product Name:Analog Output Module
Brand Name:Honeywell
Model Number:8C-PAINA1 51454470-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-PAINA1 51454470-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 8C-PAINA1 51454470-175 |
| Product Type | Analog Input Module without HART |
| Series | Honeywell Series 8 I/O |
| Input Channels | 16 Channels |
| Input Signal | 4–20 mA DC |
| Input Type | Single-ended analog input |
| A/D Resolution | 16-bit |
| Voltage Rating | 24 VDC |
| Module Current Rating | 105 mA |
| Input Scan Rate | 50 ms |
| Hardware Accuracy | ±0.075% Full Scale |
| Isolation | 1000 VAC RMS / ±1000 VDC |
| Compatible IOTA | 8C-TAIXA1 / 8C-TAIXB1 |
| Dimension | Approx. 152 × 120 × 65 mm |
| Weight | Approx. 0.42 kg |
| Mounting Type | IOTA plug-in installation |
The 8C-PAINA1 51454470-175 Analog Input Module is engineered for dependable signal acquisition in Honeywell Series 8 process automation systems. Designed for single-ended high-level analog input applications, the module efficiently processes 4–20 mA current signals from transmitters, sensors, and field instrumentation while maintaining stable and accurate performance in demanding industrial environments.
Integrated within the Honeywell Series 8 architecture, models including 8C-PAINA1, 8C-PAIH54, and 8C-PAIHA1 provide flexible analog input solutions for distributed control systems. The module supports fast scan rates, galvanic isolation, and advanced diagnostic functionality, helping improve signal integrity and system reliability across critical control applications.
Its compact plug-in IOTA structure simplifies installation and maintenance while reducing cabinet space requirements. With conformal coating protection and redundancy-ready capability, the module is suitable for harsh operating conditions requiring long-term operational stability.
Q1: What is the main purpose of the 8C-PAINA1 module?
A1: It is designed to receive and process 4–20 mA analog input signals in industrial control systems.
Q2: Does the 8C-PAINA1 support HART communication?
A2: No, this module is intended for analog input applications without HART functionality.
Q3: How many input channels are available on the module?
A3: The module supports 16 single-ended analog input channels.
Q4: Can the module operate in harsh industrial environments?
A4: Yes, its conformal coated design helps protect against moisture, dust, and temperature extremes.
Q5: Which IOTA assemblies are compatible with 8C-PAINA1?
A5: The module is compatible with 8C-TAIXA1 and 8C-TAIXB1 IOTA assemblies.
| I/O Module (Coated) | Description |
|---|---|
| 8C-PAIH54 | High-level AI HART, Differential |
| 8C-TAIDA1 | AI IOTA |
| 8C-TAIDB1 | AI IOTA Redundant |
| 8C-PAIHA1 | High-level AI HART, Single-ended |
| 8C-PAINA1 | High-level AI w/o HART, Single-ended |
| 8C-TAIXA1 | AI IOTA |
| 8C-TAIXB1 | AI IOTA Redundant |
| 8C-PAIMA1 | Low-level AI – RTD & TC |
| 8C-TAIMA1 | Low-level AI IOTA |
| 8C-PAOHA1 | Analog Output HART |
| 8C-PAONA1 | Analog Output w/o HART |
| 8C-TAOXA1 | AO IOTA |
| 8C-TAOXB1 | AO IOTA Redundant |
| 8C-PDILA1 | Digital Input 24V |
| 8C-PDISA1 | Digital Input Sequence of Events |
| 8C-PDIPA1 | Digital Input 24V Pulse Accumulation |
| 8C-TDILA1 | DI 24V IOTA |
| 8C-TDILB1 | DI 24V IOTA Redundant |
