Product Name: AF100 Field Communcation Interface
Brand Name: ABB
Model Number: CI810V2 3BSE013224R1
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Industrial Communication Module | Ethernet Communication (100 Mbps) |
| ABB System 800xA | Profibus DP (up to 12 Mbps) |
| AC 800M Control System | CANopen Interface Module |
| Distributed Control System (DCS) | Real-Time Control System |
| Industrial Automation Network | Hot-Swappable Module |
| Multi-Protocol Gateway | Redundant Communication Architecture |
| Industrial Fieldbus Integration |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB CI810V2 3BSE013224R1 Field Communcation Interface |
| Manufacturer | ABB |
| Product Type | Field Communcation Interface |
| Part Number | CI810V2 3BSE013224R1 |
| Weight | 0.5 kg |
| Estimated shipping dimensions | 16.8x8.5x12cm |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Temperature | -20°C ~ +60°C (non-condensing) |
| Humidity | 5% ~ 95% (non-condensing) |
| Protection class | IP20 (panel mounting) |
| Communication cycle | ≤1ms (high-speed mode) |
| Data transmission rate | Ethernet 100Mbps, Profibus up to 12Mbps |
| DC power | 24V DC (±10%) |
| Power consumption | Approximately 10W (typical value) |
The ABB CI810V2 3BSE013224R1 is a high-performance industrial communication interface designed by ABB for distributed control and automation systems. It enables seamless multi-protocol communication between controllers, field devices, and third-party automation equipment, supporting efficient data exchange in complex industrial networks.
The module is widely used in ABB System 800xA environments and AC 800M-based architectures. With support for Ethernet, Profibus DP, and CANopen, it provides flexible and reliable integration across heterogeneous automation systems. Its high-speed communication cycle (≤1 ms) ensures real-time control and monitoring in critical industrial applications.
Power Supply Configuration
The ABB CI810V2 3BSE013224R1 operates on a 24 V DC power supply with ±10% tolerance. Proper wiring, stable voltage input, and correct polarity are required to ensure reliable operation and communication stability.
Communication Setup
The module must be configured according to the selected communication protocol (Ethernet, Profibus DP, or CANopen). Proper network addressing, topology setup, and protocol matching are required for seamless data exchange between devices.
System Integration
The CI810V2 integrates into ABB System 800xA and AC 800M architectures. It acts as a communication bridge between controllers and field-level devices, enabling unified control and monitoring across the system.
Network Configuration
Network parameters such as IP settings, baud rate (for Profibus), and cycle time (≤1 ms) must be configured according to system requirements. Proper configuration ensures low latency, stable communication, and high system responsiveness.
Installation Setup
The module should be installed on a panel-mounted rack with IP20 protection compliance. Adequate ventilation and proper grounding are required to maintain stable operation in industrial environments.
Maintenance & Diagnostics
The module supports real-time self-diagnostics, including monitoring of temperature, voltage, and communication status. Faults can be identified via LED indicators or remote ABB engineering software, enabling quick troubleshooting and minimal downtime.
