ABB CI854AK01 3BSE030220R1 CI854AK01 PROFIBUS-DP/V1 interface Original new

ABB CI854AK01 3BSE030220R1 CI854AK01 PROFIBUS-DP/V1 interface Original new

Product Name:CI854AK01 PROFIBUS-DP/V1 interface

Brand Name:ABB

Model Number:CI854AK01 3BSE030220R1

Country of Origin:SWEDEN

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

Overview
How to get price
Specifications
Description
Applications
Technical Data Summary
Environment and Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	ABB
Model Number:	CI854AK01 3BSE030220R1
Country of Origin:	SWEDEN
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

How to get price

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	CI854AK01 3BSE030220R1, ABB PROFIBUS-DP/V1 communication interface module for AC 800M control systems.
Product Type:	Industrial Communication Module designed for controller-to-field device networking.
Protocol Type:	PROFIBUS-DP/V1 supporting high-speed distributed automation communication.
Communication Channels:	One dedicated PROFIBUS communication channel for industrial networking applications.
Communication Speed:	Up to 12,000 kbit/s (12 Mbit/s) for fast and reliable data transmission.
Package Contents:	Includes CI854 Communication Interface and TP854 Baseplate for complete installation.
System Compatibility:	Compatible with ABB AC 800M controllers and ABB 800xA Distributed Control System platforms.
Installation:	Modular DIN/rack-mounted communication interface for industrial control cabinets.
Dimensions:	Compact industrial module, gross volume approximately 1.392 dm³.
Net Weight:	Approximately 0.59 kg.
Country of Origin:	India.
Product Status:	Spare part for legacy systems; CI854BK01 (3BSE069449R1) recommended for new installations.

Description

The CI854AK01 3BSE030220R1 is an industrial communication interface module developed for ABB AC 800M controllers within the ABB 800xA automation platform. Supporting the PROFIBUS-DP/V1 communication protocol, this module enables reliable, high-speed data exchange between controllers and distributed field devices, helping to improve system performance and process efficiency. With one communication channel operating at speeds up to 12 Mbit/s, it is ideal for demanding industrial networking applications.

Supplied with the CI854 communication interface and TP854 baseplate, the CI854AK01 3BSE030220R1 offers straightforward installation and dependable integration into existing ABB control architectures. Its robust design ensures stable communication, minimizes network latency, and supports continuous operation in mission-critical automation environments.

Compatible with multiple AC 800M hardware and software versions, the CI854AK01 3BSE030220R1 remains a trusted spare part for maintaining legacy ABB 800xA systems. For new installations, the newer CI854BK01 (3BSE069449R1) is recommended, while this module continues to provide reliable replacement support for existing PROFIBUS-based control networks.

Applications

Power plants: Connects AC 800M controllers with PROFIBUS field devices for turbine control, generator monitoring, and plant automation.
Substations: Supports communication between intelligent electronic devices (IEDs), protection relays, and distributed control systems.
Chemical plants: Integrates field instruments, remote I/O, and process controllers for continuous production automation.
Steel mills: Provides reliable industrial networking for rolling mills, furnace automation, and heavy-duty manufacturing equipment.
Oil & gas facilities: Enables communication between controllers, remote stations, and field instrumentation in refinery and pipeline applications.
Water treatment plants: Connects distributed process equipment for pumping stations, filtration systems, and monitoring devices.
Machinery manufacturing plants: Supports robotic production lines, automated assembly equipment, and industrial machine communication through PROFIBUS networks.

Technical Data Summary

Designed for ABB AC 800M controllers within the 800xA automation platform.
Supports the industry-standard PROFIBUS-DP/V1 communication protocol.
Single communication channel provides reliable controller-to-device networking.
Maximum communication speed reaches 12 Mbit/s for efficient industrial data transfer.
Delivered with TP854 baseplate for simplified installation.
Modular architecture allows easy replacement and maintenance.
Optimized for distributed process automation and industrial communication.
Supports stable long-term operation in demanding control environments.

Environment and Certification

Built for continuous operation in industrial automation applications.
Designed to maintain reliable communication under demanding production conditions.
Suitable for power generation, process industries, manufacturing, and infrastructure automation.
Manufactured according to ABB industrial quality standards.
Product is intended as a spare part for legacy installations commissioned before 22 July 2017.
Not compliant with RoHS 2 (2011/65/EU) for new installations due to legacy product status.
Rugged modular construction supports long service life and dependable operation.
Compatible with multiple versions of ABB AC 800M hardware and software platforms.

FAQ

Q1: What is the primary function of the CI854AK01 3BSE030220R1?
A1: The CI854AK01 3BSE030220R1 enables PROFIBUS-DP/V1 communication between ABB AC 800M controllers and distributed field devices.

Q2: What communication protocol does the CI854AK01 support?
A2: It supports the PROFIBUS-DP/V1 industrial communication protocol with data transfer speeds up to 12 Mbit/s.

Q3: Which ABB systems are compatible with the CI854AK01?
A3: The module is designed for ABB AC 800M controllers used within the ABB 800xA distributed control system.

Q4: What accessories are included with the CI854AK01 package?
A4: The package includes the CI854 communication interface and the TP854 baseplate for installation.

Q5: Is the CI854AK01 recommended for new automation projects?
A5: No. The CI854AK01 is intended as a spare part for existing systems, while CI854BK01 (3BSE069449R1) is the recommended model for new installations.
