Product Name: Common Processor Module
Brand Name: ABB
Model Number: CPM810
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB CPM810 Common Processor Module |
| Manufacturer | ABB |
| Product Type | Common Processor Module |
| Part Number | CPM810 |
| Weight | 0.16 kg |
| Estimated shipping dimensions | 4.5x10.6x12cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Processor | 32-bit RISC-based microprocessor |
| Clock Speed | 40 MHz |
| Power Supply | 5 V DC |
| Flash | 64 MB |
| RAM | 32 MB SDRAM |
| Power Consumption | Typical: 8 W (max 10 W) |
| Standard | 0°C to +55°C (32°F to 131°F) |
| Extended | -25°C to +70°C (with derating) |
| Relative Humidity | 5–95% (non-condensing) |
The ABB CPM810 Common Processor Module is a versatile industrial computing unit designed to serve as the central processing core of ABB automation and control systems. Equipped with a 32-bit RISC-based microprocessor operating at 40 MHz, the module delivers reliable computing performance for executing control logic, managing system communications, and handling real-time process data. Its combination of 64 MB Flash memory and 32 MB SDRAM provides ample resources for firmware storage, application execution, and efficient data management.
Engineered for demanding industrial environments, the CPM810 offers a compact and energy-efficient design with a typical power consumption of only 8 W. It supports operation in standard temperature conditions from 0°C to +55°C and can withstand extended temperatures ranging from -25°C to +70°C with appropriate derating. With high humidity tolerance and proven industrial reliability, the CPM810 is well suited for continuous operation in process industries, manufacturing facilities, and critical automation applications.
The CPM810 functions as the primary processing and control module within ABB automation systems, responsible for executing user programs, control algorithms, and system-level tasks. It processes real-time input and output data, manages memory resources, and coordinates communication between controllers, I/O modules, operator stations, and other system components. This enables stable and efficient operation of complex industrial processes requiring precise monitoring and control.
In addition to its computing capabilities, the module serves as a central platform for system coordination and data handling. It supports the execution of automation strategies, process optimization routines, and diagnostic functions while maintaining reliable communication throughout the control network. By providing dependable processing power and system integration capabilities, the CPM810 helps ensure consistent performance, operational efficiency, and high availability in industrial control applications.
The ABB CPM810 is designed for seamless integration within ABB control system architectures and is compatible with a wide range of ABB automation components, including:
Its proven compatibility, stable performance, and industrial-grade reliability make the CPM810 a critical processing component for ABB control and automation solutions.
