ABB D0818 3BSE069053R1 DO818 Digital Output 24V 32 ch Ready For Ship

ABB D0818 3BSE069053R1 DO818 Digital Output 24V 32 ch Ready For Ship

Product Name:Digital Output 24V 32 ch

Brand Name:ABB

Model Number:D0818 3BSE069053R1

Country of Origin:SWEDEN

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

abb d0818 3bse069053r1 do818 digital output 24v 32 ch ready for ship-1

Overview
Get your discount today
Specifications
Description
Applications
Technical Data Summary
Environment and Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	ABB
Model Number:	D0818 3BSE069053R1
Country of Origin:	SWEDEN
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	DO818 3BSE069053R1, ABB 24 V DC digital output module for S800 I/O and 800xA automation systems.
Product Type:	Digital Output I/O Module designed for industrial automation and distributed control applications.
Output Channels:	32 digital output channels, arranged in two isolated groups of 16 channels.
Output Voltage:	24 V DC digital output for industrial field devices and control circuits.
Output Current:	Up to 0.5 A per channel, supporting reliable switching of industrial loads.
Protection Features:	Integrated short-circuit protection enhances system safety and operational reliability.
Compatible Termination Units:	Supports TU818, TU819, and TU830 module termination units.
System Compatibility:	Designed for ABB S800 I/O, 800xA, and Compact Product Suite control platforms.
Dimensions:	45 × 119 × 102 mm (W × H × D).
Net Weight:	Approximately 0.20 kg.
Environmental Compliance:	RoHS compliant according to EU Directive 2011/65/EU.

Description

The DO818 3BSE069053R1 is a high-density digital output module designed for the ABB S800 I/O platform and ABB 800xA distributed control systems. Featuring 32 isolated 24 V DC output channels, divided into two independent groups of 16, the module delivers dependable signal switching for industrial automation and process control applications. With a 0.5 A output rating per channel and integrated short-circuit protection, it provides reliable operation in demanding production environments.

Engineered for seamless integration with TU818, TU819, and TU830 module termination units, the DO818 3BSE069053R1 simplifies wiring, installation, and maintenance. Its compact design, high channel density, and robust electrical isolation improve system reliability while reducing cabinet space and installation costs.

Compatible with ABB S800 I/O, 800xA, and Compact Product Suite architectures, the DO818 3BSE069053R1 is widely used in power generation, manufacturing, petrochemical, water treatment, and infrastructure projects where stable digital output control is essential for continuous industrial operation.

Applications

Power plants: Controls relays, motor starters, circuit breakers, and auxiliary equipment within turbine and generator automation systems.
Substations: Provides reliable digital output signals for switchgear control, protection systems, and substation automation.
Chemical plants: Operates valves, pumps, alarms, and field actuators within continuous process control systems.
Steel mills: Controls heavy industrial equipment, conveyor systems, and production machinery operating in demanding environments.
Machinery manufacturing plants: Drives robotic cells, automated production lines, packaging systems, and assembly equipment.
Water treatment facilities: Controls pumps, dosing units, valves, and filtration equipment through distributed I/O networks.
Oil & gas facilities: Supports digital control of field devices, shutdown systems, and process automation equipment.

Technical Data Summary

Designed for ABB S800 I/O distributed automation systems.
Provides 32 isolated 24 V DC digital output channels.
Two independent groups of 16 outputs improve system isolation and reliability.
Maximum 0.5 A output current per channel supports industrial control loads.
Integrated short-circuit protection increases equipment safety and minimizes downtime.
Compatible with TU818, TU819, and TU830 termination units.
Compact module design reduces control cabinet space requirements.
Suitable for continuous industrial automation and process control applications.

Environment and Certification

Fully compliant with EU RoHS Directive 2011/65/EU.
Designed for long-term operation in demanding industrial environments.
Industrial-grade isolation improves electrical noise immunity and operational stability.
Suitable for power generation, chemical processing, manufacturing, and infrastructure automation.
Compact construction supports high-density cabinet installation.
Manufactured according to ABB industrial quality standards.
WEEE Category 5 compliant for environmental product management.
Built for dependable performance in mission-critical industrial control systems.
