ABB DO630 3BHT300007R1 DO630 Digital Output 16ch 250VAC Ready For Ship

ABB DO630 3BHT300007R1 DO630 Digital Output 16ch 250VAC Ready For Ship

Product Name:DO630 Digital Output 16ch 250VAC

Brand Name:ABB

Model Number:DO630 3BHT300007R1

Country of Origin:SWEDEN

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

abb do630 3bht300007r1 do630 digital output 16ch 250vac ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	ABB
Model Number:	DO630 3BHT300007R1
Country of Origin:	SWEDEN
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model	DO630
Product ID	3BHT300007R1
Product Type	Digital Output Module
Channel Type	Digital Output (DO)
Number of Output Channels	16 Channels
Output Isolation	16 Isolated Groups
Rated Output Voltage	250 VAC
System Compatibility	ABB S600 I/O System
Application Platform	Advant OCS / Advant Controller 160
Product Depth	252 mm
Product Height	273 mm
Product Width	40 mm
Net Weight	1.32 kg
RoHS Compliance	EU Directive 2011/65/EU
WEEE Category	Small Equipment

Description

DO630 3BHT300007R1 is a high-performance digital output module engineered for reliable signal switching and control tasks in ABB industrial automation environments. Featuring 16 isolated output channels rated up to 250 VAC, the module ensures dependable operation in demanding process control applications where electrical isolation and output integrity are essential.

Designed for seamless integration with ABB S600 I/O systems and Advant OCS platforms, DO630 3BHT300007R1 supports distributed control architectures by providing stable and accurate output signal management. Its grouped isolation structure enhances system safety while minimizing the risk of interference between field devices.

Commonly deployed alongside ABB modules such as DO620, DI620, AI630, and AO650, the DO630 3BHT300007R1 helps improve operational efficiency in power generation, manufacturing, process industries, and infrastructure automation projects. Its rugged construction, compact design, and long service life make it a dependable choice for critical industrial control systems.

Applications

Power Plants: Used for generator auxiliary control, relay actuation, alarm signaling, and turbine automation systems.
Substations: Supports switchgear operation, circuit breaker control, status indication, and electrical distribution management.
Chemical Plants: Integrates with DCS platforms for valve control, process sequencing, and field device activation.
Steel Mills: Provides reliable output control for rolling mills, conveyor systems, and high-temperature production processes.
Machinery Manufacturing Plants: Controls robotic stations, packaging machinery, assembly lines, and automated production equipment.
Water & Wastewater Facilities: Enables pump control, treatment process automation, and remote monitoring systems.
Oil & Gas Industry: Supports critical process control, safety interlocks, and field equipment operation in harsh industrial environments.

Features

16 digital output channels for flexible control applications
Supports output voltages up to 250 VAC
Individual group isolation enhances operational safety
Designed for ABB S600 I/O architecture
Compatible with Advant OCS control systems
Compact industrial-grade construction
High reliability for continuous-duty operation
Easy installation and maintenance
Suitable for distributed automation networks
Long service life in demanding industrial environments

Functions

Executes digital switching commands from the control system
Drives relays, contactors, solenoids, and field actuators
Provides isolated output signals for enhanced system protection
Facilitates automated process sequencing
Supports equipment start/stop control operations
Enables alarm and event signaling functions
Interfaces between controllers and field devices
Improves operational reliability within industrial automation systems

FAQ

Q1: What is the DO630 3BHT300007R1 module used for?
A1: The DO630 is a digital output module used to control relays, contactors, valves, and other field devices in ABB automation systems.

Q2: How many output channels does the DO630 provide?
A2: The module features 16 isolated digital output channels for reliable and secure signal switching.

Q3: Which control systems support the DO630 3BHT300007R1?
A3: It is compatible with ABB S600 I/O platforms, Advant OCS systems, and Advant Controller 160 applications.

Q4: What is the maximum output voltage of the DO630 module?
A4: The DO630 supports output voltages up to 250 VAC, making it suitable for a wide range of industrial control tasks.

Q5: What are the benefits of using the DO630 module?
A5: Key advantages include high reliability, isolated outputs, easy system integration, compact design, and dependable industrial performance.
