Product Name:DO818 Digital Output 24V 32 ch
Brand Name:ABB
Model Number:DO818 3BSE069053R1
Country of Origin:Sweden
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
DO818 3BSE069053R1 |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | DO818 (3BSE069053R1), ABB S800 digital output module for industrial automation control systems |
| Output Channels | 32 channels, divided into two isolated groups of 16 channels for safe signal separation |
| Output Voltage | 24 V DC industrial standard output for actuator and device control |
| Output Current | 0.5 A per channel with short-circuit protection for system safety |
| Isolation | Channel group isolation ensuring stable and interference-resistant operation |
| Compatible Units | TU818, TU819, TU830 module termination units for flexible installation |
| Dimension | 119 mm × 45 mm × 102 mm compact modular design for control cabinets |
| Weight | 0.2 kg lightweight construction for easy DIN-rail integration |
The DO818 (3BSE069053R1) is an ABB industrial digital output module designed for high-density signal switching in advanced automation and process control systems. As part of ABB’s S800 I/O family, the DO818 provides reliable 24V DC output control for demanding industrial environments.
The DO818 3BSE069053R1 features 32 output channels divided into two isolated groups of 16 channels, ensuring safe and stable operation in complex control architectures. With short-circuit protection and robust electrical isolation, it supports secure actuator and field device control in critical applications.
Engineered for integration with ABB module termination units such as TU818, TU819, and TU830, the DO818 delivers flexible installation, high channel density, and dependable performance in distributed automation systems.
Power plants: Used for generator control systems, relay logic, and auxiliary equipment switching operations.
Substations: Enables protection relay control, breaker operation, and signal acquisition systems.
Chemical plants: Supports process automation, valve control, and intrinsically safe switching functions.
Steel mills: Provides reliable digital output control in high-temperature and EMI-heavy environments.
Machinery manufacturing plants: Applied in automated production lines, robotics, and packaging equipment control systems.
Q1: What is the main function of DO818 (3BSE069053R1)?
A1: It provides 32-channel 24V digital output control for ABB automation systems.
Q2: How many output channels does DO818 support?
A2: It supports 32 channels divided into two isolated groups of 16.
Q3: Is the DO818 protected against short circuits?
A3: Yes, each output channel is short-circuit protected.
Q4: Which termination units are compatible with DO818?
A4: It works with TU818, TU819, and TU830 module termination units.
Q5: What industries commonly use this module?
A5: It is widely used in power plants, substations, chemical plants, and manufacturing automation systems.
