Product Name: Multi-Function Controller Termination Unit
Brand Name: ABB
Model Number: NTMF01
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB NTMF01 Multi-Function Controller Termination Unit |
| Manufacturer | ABB |
| Product Type | Multi-Function Controller Termination Unit |
| Part Number | NTMF01 |
| Estimated shipping dimensions | 20.3 cm x 2.5 cm x 17.8 cm |
| Weight | 0.3 kg |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Power Requirements | +24 VDC ± 10% |
| Current Consumption | 160 mA (Typical) to 250 mA (Max) |
| Communication Ports | 2 x RS-232-C Serial Ports |
| Control Station Link | 1 x Serial Link (via NTCS04 Termination Unit) |
| Mounting | Mounts on NFTP01 Field Termination Panel |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Relative Humidity | 5% to 90% (Non-condensing) |
The ABB NTMF01 Multi-Function Controller Termination Unit (TMF) is a specialized interface module designed for use within ABB Bailey INFI 90® distributed control systems. It provides the essential termination point between process control modules and plant equipment, ensuring reliable communication and signal integrity throughout the system. Equipped with dual RS-232-C serial port termination and a dedicated control station communication link, the NTMF01 enables seamless data exchange between controllers, operator stations, and external peripheral devices.
Engineered to support both standard and redundant control architectures, the NTMF01 is compatible with IMMFC03, IMMFC04, and IMMFC05 Multi-Function Controllers, as well as INICT01, INPPT01, and INPCT01 transfer modules. Its robust design allows continuous communication between process modules, computers, printers, event recorders, and control stations while providing automatic failover support in redundant controller applications. As a critical component of the INFI 90® communication infrastructure, the NTMF01 helps ensure dependable system operation, enhanced availability, and uninterrupted control system connectivity.
The NTMF01 performs the following key functions:
Multi-Function Controller Communication
The NTMF01 provides RS-232-C termination for IMMFC03, IMMFC04, and IMMFC05 controllers, enabling reliable communication with computers, terminals, printers, and event recording devices.
Control Station Connectivity
It supports communication links between controllers and operator stations through the NTCS04 Termination Unit, allowing effective process monitoring and control.
Redundant Controller Systems
The unit supports redundant controller configurations by maintaining communication paths for both primary and backup controllers, ensuring continuous system operation during failover events.
INFI-NET® and Plant Loop Communications
The NTMF01 serves as a termination interface within INFI-NET® and Plant Loop architectures, facilitating dependable data exchange across networked control systems.
Transfer Module Integration
It provides termination and communication support for INICT01, INPPT01, and INPCT01 transfer modules, ensuring seamless connectivity between system components.
Process Automation and Industrial Control
The NTMF01 is widely used in industrial automation applications where reliable controller communication and uninterrupted process control are essential.
The ABB NTMF01 Multi-Function Controller Termination Unit is fully compatible with the ABB Bailey INFI 90® distributed control system platform. It supports IMMFC03, IMMFC04, and IMMFC05 Multi-Function Controllers, as well as INICT01 Computer Transfer Modules, INPPT01 Plant Loop Transfer Modules, and INPCT01 Communication Transfer Modules. The unit interfaces with the NTCS04 Control I/O Termination Unit to provide communication links for NDCS03 Digital Control Stations and IISAC01 Analog Control Stations. Designed for installation on the NFTP01 Field Termination Panel, the NTMF01 integrates seamlessly into INFI 90®, INFI-NET®, and Plant Loop network architectures, providing reliable RS-232-C serial communications and supporting both standalone and redundant controller configurations.
