ABB PM860K01 3BSE018100R1 Processor Unit Kit

ABB PM860K01 3BSE018100R1 Processor Unit Kit

Product Name: Processor Unit Kit

Brand Name: ABB

Model Number: PM860K01 3BSE018100R1

Place of Origin: SWEDEN

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb pm860k01 3bse018100r1 processor unit kit-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The ABB PM860K01 3BSE018100R1 Processor Unit Kit is a powerful industrial controller designed to serve as the central processing unit within ABB automation and control systems. Based on the MPC860 processor architecture and operating at a clock frequency of 48 MHz, the PM860K01 delivers fast and reliable execution of control strategies, communication functions, and process management tasks. With 16 MB of memory, including 10.346 MB of application RAM and integrated flash memory for data and program storage, the unit provides the resources required for complex industrial automation applications.

Designed for high-performance process control environments, the PM860K01 supports up to 32 applications per controller, 64 programs per application, 128 diagrams per application, and 32 control tasks with multiple cycle times. Operating from a standard 24 V DC power supply, it combines advanced processing capabilities with energy-efficient operation, making it an ideal solution for mission-critical industrial automation systems that require reliability, scalability, and long-term operational stability.

Functions

Executes advanced control algorithms and automation programs.
Processes real-time operational data from field devices and control networks.
Manages multiple applications, programs, and tasks within a single controller.
Supports communication and data exchange across industrial automation systems.
Coordinates process monitoring, diagnostics, and control operations.
Stores application programs and system data using integrated flash memory.
Enables distributed control and supervisory automation functions.
Supports complex industrial processes requiring high-performance control capabilities.

Specifications

Product Name	ABB PM860K01 3BSE018100R1 Processor Unit Kit
Manufacturer	ABB
Product Type	Processor Unit Kit
Part Number	PM860K01 3BSE018100R1
Weight	0.9kg
Estimated shipping dimensions	19x12x13.8cm
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Clock Frequency	48 MHz
Memory	16 MB
RAM available for application	10.346
Flash memory for storage	Yes
Processor type	MPC860
No. of applications per controller	32
No. of programs per application	64
No. of diagrams per application	128
No. of tasks per controller	32
Number of different cycle times	32
Power supply	24 V DC (19.2-30 V DC)
Power consumption	+24 V typ/max 180 / 300 mA
Power dissipation	4.32 W

Advantage

High-performance MPC860 processor with 48 MHz clock frequency.
Large 16 MB memory capacity supports advanced automation applications.
Dedicated application RAM enhances processing efficiency and responsiveness.
Integrated flash memory provides secure storage of programs and configuration data.
Supports up to 32 applications and 32 simultaneous control tasks.
Flexible architecture allows management of complex multi-process environments.
Reliable ABB engineering ensures long-term operational stability.
Energy-efficient operation with low power consumption and heat dissipation.
Scalable platform suitable for both small and large automation systems.
Reduces system complexity by consolidating multiple control functions within a single processor unit.

Performance & Efficiency

Delivers fast execution of control logic and automation tasks through a 48 MHz processor.
Supports efficient multitasking with up to 32 independent control tasks.
Provides rapid access to application data through 10.346 MB of available RAM.
Enables reliable long-term storage through integrated flash memory technology.
Supports up to 32 different cycle times for optimized process control performance.
Maintains stable operation with low power consumption of 180 mA typical at 24 V DC.
Optimizes controller responsiveness in demanding industrial applications.
Improves plant productivity through accurate real-time monitoring and control.

Installation & Integration

The ABB PM860K01 3BSE018100R1 Processor Unit Kit is designed for seamless integration into ABB industrial automation architectures. Operating on a 24 V DC power supply with an input range of 19.2–30 V DC, it can be easily incorporated into existing control systems and distributed automation networks. Its compact design simplifies installation within control cabinets, while its support for multiple applications, programs, tasks, and cycle times enables efficient deployment in both standalone and large-scale control environments. The processor integrates smoothly with ABB I/O systems, communication modules, and engineering tools, ensuring simplified commissioning, maintenance, and future system expansion.
