ABB RETA-02 Ethernet Adapter Module

Product Name: Ethernet Adapter Module

Brand Name: ABB

Model Number: RETA-02

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Contact Info
Parameter
Introduction
Features
Function
FAQ
Product Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter

Product Name	ABB RETA-02 Ethernet Adapter Module
Manufacturer	ABB
Product Type	Ethernet Adapter Module
Part Number	RETA-02
Estimated shipping dimensions	9.3x6.1x3.5cm
Weight	0.06kg
Place of shipment	Xiamen, China
Country of origin	Sweden
Mounting	Into the option slot on the control board of the drive.
Degree of protection	IP20
Settings	Parameters (set through the drive), 8-way DIP switch for intranet IP address selection
Connectors	34-pin parallel bus connector, RJ-45 connector
Current consumption	380 mA average (5 V), supplied by the control board of the drive
Estimated min. lifetime	100 000 h
Compatible devices	Ethernet standard IEEE 802.3 and 802.3u devices
Medium	10base-TX or 100base-TX
Connector	RJ-45
Maximum segment length	100 m
Topology	Bus, star
Serial communication type	Half and full Duplex
Transfer rate	10/100 Mbps

Introduction

The ABB RETA-02 Ethernet Adapter Module is an optional communication interface designed to enable Ethernet connectivity for ABB drives. It allows ABB drives to integrate seamlessly into industrial Ethernet networks and operate as slave devices within automation systems.

The RETA-02 supports both Modbus/TCP and PROFINET communication protocols, enabling flexible integration with a wide range of Ethernet-based control systems. It provides real-time control, monitoring, and parameter adjustment capabilities, making it a powerful solution for modern industrial automation.

The module is widely used in applications requiring remote drive control, process monitoring, and network-based automation.

Features

Supports Modbus/TCP and PROFINET industrial Ethernet protocols
Enables ABB drives to function as Ethernet slave devices
Real-time control commands (Start, Stop, Run enable)
Motor speed and torque reference control via Ethernet
PID controller integration with process actual values and references
Real-time monitoring of drive status and operational values
Remote parameter configuration and fault reset capability
Supports 10/100 Mbps Ethernet communication (10Base-TX / 100Base-TX)
RJ-45 Ethernet connector for network communication
34-pin parallel bus connector for drive interface
IP20 protection rating for industrial cabinet installation
Supports half-duplex and full-duplex communication modes
Maximum segment length: 100 meters
Configurable via drive parameters and 8-way DIP switch
Average power consumption: 380 mA at 5 V
Estimated lifetime: up to 100,000 hours
Compact and lightweight design for easy installation
Supports bus and star network topology
Designed for reliable long-term industrial operation

Function

The primary function of the ABB RETA-02 Ethernet Adapter Module is to provide Ethernet-based communication between ABB drives and external control systems.

It enables operators to send control commands such as start, stop, and speed reference directly to the drive while also receiving real-time status information. The module allows full remote access to drive parameters, fault diagnostics, and system monitoring.

In addition, the RETA-02 supports integration with PID control loops by allowing process values and references to be exchanged over Ethernet networks, improving automation precision and system responsiveness.

FAQ

1. What is the protection rating of the ABB RETA-02?

The ABB RETA-02 has an IP20 protection rating for installation inside industrial cabinets.

2. Which communication protocols does the ABB RETA-02 support?

The ABB RETA-02 supports Modbus/TCP and PROFINET Ethernet communication protocols.

3. Can the ABB RETA-02 control ABB drives remotely?

Yes, the ABB RETA-02 allows remote control of ABB drives, including Start, Stop, Run enable, and speed or torque reference commands.

4. What type of Ethernet does the ABB RETA-02 support?

The ABB RETA-02 supports 10Base-TX and 100Base-TX Ethernet standards.

5. What connectors are used in the ABB RETA-02?

The ABB RETA-02 uses an RJ-45 Ethernet connector and a 34-pin parallel bus connector for drive communication.

6. What is the maximum communication distance of the ABB RETA-02?

The ABB RETA-02 supports a maximum Ethernet segment length of 100 meters.
