Product Name:Analog Output
Brand Name:Honeywell
Model Number:900B01-0101
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
900B01-0101 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 900B01-0101 |
| Type | Analog Output Module |
| Output Channels | 4 isolated outputs |
| Output Range | 0 to 21.8 mA (configurable per channel) |
| Load Resistance | Max 750 ohms |
| Resolution | 12-bit D/A conversion |
| Accuracy | ±0.1% full scale |
| Isolation | 500 VDC channel-to-channel, 600 VDC logic isolation |
| Response | Synchronous with controller execution |
| Power Supply | 5V DC / 24V DC system power |
| Dimension (H×W×D) | 137 mm × 35.6 mm × 66 mm |
| Weight | ~408 g |
The 900B01-0101 Analog Output Module is part of the Honeywell ControlEdge HC900 distributed control platform, designed to deliver precise and stable current signal control in advanced industrial automation systems. It provides 4 isolated analog outputs with configurable ranges from 0 to 21.8 mA, enabling flexible integration into complex process control architectures.
The 900B01-0101 supports high-accuracy signal transmission with 12-bit resolution and 0.1% full-scale precision, ensuring reliable performance for demanding control loops. Models such as 900B08-0202 and 900B01-0301 extend system scalability within the same platform architecture.
Engineered for harsh industrial environments, the 900B01-0101 features galvanic isolation, diagnostic monitoring, and failsafe functionality, making it ideal for continuous and safety-critical operations in modern automation systems.
Q1: What is the main function of 900B01-0101?
A1: It provides 4-channel isolated analog current outputs for precise industrial process control.
Q2: What output range does 900B01-0101 support?
A2: It supports a configurable 0 to 21.8 mA output range per channel.
Q3: Is the module suitable for harsh environments?
A3: Yes, it features galvanic isolation and industrial-grade durability for demanding applications.
Q4: Does it support failsafe operation?
A4: Yes, it supports user-defined failsafe values in case of communication loss.
Q5: What systems is it compatible with?
A5: It integrates with Honeywell ControlEdge HC900 automation platforms and related I/O modules.
| Model | Description |
|---|---|
| 900B01-0101 | Analog Output Module, 4-channel isolated 0–21.8 mA output, high-precision industrial control module |
| 900B08-0202 | 8-channel analog output module for scalable process control applications |
| 900B01-0301 | 4-channel analog output module with enhanced current loop performance |
| 900A16-0103 | High-level analog input module for process signal acquisition |
| 900G03-0202 | Digital input module for AC voltage signal monitoring |
| 900H03-0202 | Digital output module for AC load switching control |
| 900P01-0301 | 60W AC power supply module for ControlEdge system support |
