Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330104-05-13-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-05-13-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330104-05-13-10-02-00 |
|
System Type |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 metric thread |
|
Total Length |
1.0 m (typical configuration) |
|
Cable Type |
75Ω triaxial standard cable |
|
Connector Type |
Miniature coaxial ClickLoc |
|
Linear Range |
2 mm (approx. 0.25–2.3 mm) |
|
Output Signal |
Eddy current voltage proportional output |
|
Operating Temp |
-52°C to +177°C |
|
Probe Material |
Stainless steel (SST body) |
|
Weight |
0.14kg |
|
Dimension (Probe) |
1.8x1.6x113cm |
The330104-05-13-10-02-00is part of the advanced3300 XL 8 mm Proximity Transducer System, engineered for high-precision vibration and position monitoring in industrial machinery. It delivers stable eddy-current sensing performance for fluid-film bearing equipment, ensuring reliable signal output under demanding operating conditions. Alongside related probes such as330103and330104, the system provides flexible configuration options for different installation requirements.
Built for compatibility with the3300 XL Proximitor Sensorand extension cable assemblies, the330104-05-13-10-02-00ensures accurate dynamic and static measurement response. Its robust construction supports long-term stability and interchangeability without recalibration.
Designed for harsh environments, this probe series supports industrial standards including API 670 compliance, making330104-05-13-10-02-00suitable for critical monitoring applications requiring precision, durability, and electrical noise immunity.
Q1: What is the 330104-05-13-10-02-00 used for?
A1: It is used for vibration and position measurement in rotating machinery such as turbines, compressors, and generators.
Q2: Is the 330104 probe compatible with other 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor Sensors.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operating temperatures up to +177°C depending on configuration.
Q4: What industries commonly use this probe?
A4: It is widely used in power plants, petrochemical facilities, steel mills, and manufacturing automation systems.
Q5: Does it require recalibration after replacement?
A5: No, it supports interchangeability without the need for bench calibration.
| Number | Describe |
|---|---|
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw, 4 screws required per sensor, supplied with 3300 XL panel-mount housings |
| 03200006 | Silicone self-fusing tape, 9.1-meter roll for connector protection, provides insulation and environmental sealing, not recommended inside machine casing |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools |
| 136536-01 | Connector protector adapter, enables use of pre-1998 installation tools with 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package, includes 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector, installs on extension cable to protect probe connector interface |
| 03839420 | 75Ω triaxial female connector protector, protects probe-to-extension or Proximitor sensor connections from environmental exposure |
| 04301007 | 3/8-24 probe lock nut with safety wire holes, designed to secure probe installation with safety wiring |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, used to secure probe mounting with safety wire locking |
| 330153-01 | 3300 XL connector kit, includes male/female ClickLoc connectors, sleeves, slit FEP tubing, and silicone tape |
| 330153-09 | 3300 XL ETR connector kit, high-temperature version for ETR probes and cables with ClickLoc connectors and insulation materials |
| 163356 | Connector crimp tool kit, includes connector inserts, installation instructions, compatible with 330153 kits and post-2003 probes |
