Product Name:Analog Output Module
Brand Name:HONEYWELL
Model Number:TK-HAO081
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
TK-HAO081 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Description |
Value |
|
Model |
TK-HAO081 |
|
Type |
Analog Output Module |
|
Module scan time (for the analog 0-100% output value) |
10 ms for all (8) channels |
|
Over voltage Protection |
24 VAC/VDC continuous at room temperature |
|
Drive Capability |
>2000 (Voltage) 50-750 (Current) With short circuit protection for all (8) channels. |
|
Calibrated Accuracy @ 25°C Calibration interval – |
Better than 0.1% of range (Voltage) Better than 0.15% of range (Current) 12 months typical |
|
RFI Immunity |
Error of less than 2.0% of range at 10 V/m, 27 to 1000 MHz |
|
Offset Drift with Temperature |
50 mV/°C (voltage) typical. 200 nA/°C (current) typical. |
|
Dimension |
14.0 × 12.0 × 3.5 cm |
|
Weight |
2.8 kg |
TK-HAO081 is a hazardous-area remote termination solution engineered for high-density KF module integration and stable process signal distribution. It is designed to streamline field wiring while maintaining robust communication with control systems such as Honeywell 1756 rack I/O platforms and compatible interface architectures.
The system architecture supports 8 or 16 KF module configurations, using coded FSY plug connectors to ensure secure and error-free module interfacing. A reinforced motherboard with an adapter interface enables direct system connectivity, reducing cabinet complexity and saving installation space in industrial control panels.
Built on a DIN-rail mountable metal base plate, TK-HAO081 offers redundant power supply support, LED diagnostics, and relay-based status monitoring. It enhances operational reliability, simplifies maintenance, and ensures continuous performance in hazardous industrial environments.
Q1: What is TK-HAO081 used for?
A1: It is used for hazardous-area signal termination and KF module integration in industrial control systems.
Q2: How many modules does it support?
A2: It supports flexible configurations of 8 or 16 KF modules.
Q3: Is it compatible with Honeywell systems?
A3: Yes, it integrates with Honeywell 1756 rack I/O architectures.
Q4: Does it support redundant power?
A4: Yes, it features a dual redundant power supply design for higher reliability.
Q5: How is it mounted?
A5: It is designed for DIN rail mounting according to EN 50022 standards.
| Model | Describe |
|---|---|
| IAH061 | High Level Analog Input (10V & 4–20mA), 6 I/O Channels, 20 TB Pins |
| OAH061 | Analog Output (4–20mA), 6 I/O Channels, 20 TB Pins |
| OAV061 | Analog Output (10V), 6 I/O Channels, 20 TB Pins |
| IXL061 | Thermocouple Input Module, 6 I/O Channels, 20 TB Pins |
| IXL062 | Thermocouple Input Module, 6 I/O Channels, 20 TB Pins |
| IXR061 | RTD Temperature Input Module, 6 I/O Channels, 20 TB Pins |
| IAH161 | Analog Input (Voltage & Current), 16 I/O Channels, 36 TB Pins |
| OAV081 | Analog Output (Current/Voltage), 8 I/O Channels, 20 TB Pins |
| HAI081 | Analog Input (Voltage/Current, HART Enabled), 8 I/O Channels, 36 TB Pins |
| HAO081 | Analog Output (Voltage/Current, HART Enabled), 8 I/O Channels, 20 TB Pins |
| ORC081 | Isolated Relay Output (8 NO & 8 NC, 24–220VAC), 8 I/O Channels, 36 TB Pins |
| ORC161 | Relay Output (16 NO, 24–220VAC), 16 I/O Channels, 36 TB Pin |
