ABB RXSF1 Signal Flag Relay

Product Name: Signal Flag Relay

Brand Name: ABB

Model Number: RXSF1

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Contact Info
Parameter
Introduction
Features
Function
FAQ
Product Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter

Product Name	ABB RXSF1 Signal Flag Relay
Manufacturer	ABB
Product Type	Signal Flag Relay
Part Number	RXSF1
Estimated shipping dimensions	15.5x8.5x4cm
Weight	0.24 kg
Place of shipment	Xiamen, China
Country of origin	Sweden
Operating Voltage	DC 110-125V
Reset Mode	Automatic reset
Contact Configuration	2 make, 4 break
Indication	Red flag
Internal Relay Quantity	One or two smaller relays
Contacts per Internal Relay	Three contacts
Flag Color	Red

Introduction

The ABB RXSF1 is a signal flag relay designed for electrical protection and control systems, providing reliable visual indication of system status and fault events. It is used as an operating indicator within protection schemes to clearly display relay operations through a mechanical red flag system.

Designed for DC voltage environments (110–125 V DC), the RXSF1 ensures dependable status signaling in substations, switchgear panels, and industrial power systems. It supports both voltage-operated and current-operated configurations, making it suitable for a wide range of protection and monitoring applications.

The relay plays an important role in system diagnostics by converting electrical events into clear visual indicators, helping operators quickly identify and respond to abnormal conditions.

Features

Provides clear visual indication using red mechanical flag display
Operates in 110–125 V DC control voltage systems
Supports both voltage-operated and current-operated versions
One or two internal relay configurations available
Contact options include 2 make (NO) and 4 break (NC) contacts
Flexible reset modes: manual reset or automatic reset via power loss
Automatic reset option for loss-of-voltage applications
Current-operated version supports circuit breaker trip coil monitoring
Detects and confirms trip current flow for operation verification
Compact design suitable for control panel installation
High reliability for electrical protection environments
Designed for integration with protection relays and switchgear systems
Improves fault visibility and system response efficiency
Supports continuous operation in demanding industrial conditions
Suitable for substation and industrial electrical applications

Function

The primary function of the ABB RXSF1 is to provide clear and reliable visual indication of electrical protection system events.

It monitors DC control signals and activates a mechanical red flag when a relay operation or fault condition occurs. In current-operated configurations, it also verifies circuit breaker trip coil current flow, confirming successful breaker operation.

The relay enhances system safety by translating electrical signals into visible status information, allowing operators to quickly assess system conditions and take corrective action.

Typical applications include:

Power transmission and distribution substations
Circuit breaker monitoring systems
Electrical protection relay schemes
Industrial switchgear systems
Substation automation systems
Power generation facilities
Industrial electrical control panels

FAQ

1. Can the ABB RXSF1 be used for circuit breaker monitoring?

Yes, the ABB RXSF1 current-operated version can monitor circuit breaker trip coil current to confirm operation.

2. What reset options are available for the ABB RXSF1?

The ABB RXSF1 supports manual reset and automatic reset via DC power loss or restoration.

3. How many internal relays can the ABB RXSF1 have?

The ABB RXSF1 can include one or two internal relays depending on configuration.

4. What type of contacts does the ABB RXSF1 provide?

The ABB RXSF1 typically provides 2 make (NO) contacts and 4 break (NC) contacts.

5. Where is the ABB RXSF1 commonly used?

The ABB RXSF1 is commonly used in substations, switchgear panels, and industrial power systems.

6. Why is visual indication important in the ABB RXSF1?

The ABB RXSF1 provides immediate fault visibility, helping operators respond quickly to system events.
