Product Name: Power Supply Module
Brand Name: ABB
Model Number: SD812F 3BDH000014R1
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB SD812F 3BDH000014R1 Power Supply Module |
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Part Number | SD812F 3BDH000014R1 |
| Weight | 0.54 kg |
| Estimated shipping dimensions | 6.5x14.5x17cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Wide Range AC Input | 85 - 264 V AC |
| DC Input | 120 - 300 V DC |
| Nominal | 24 V DC |
| Rated Current | 10A |
| Rated Power | 240W |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 10% to 95% RH (non-condensing) |
The ABB SD812F 3BDH000014R1 Power Supply Module is a high-performance industrial power supply designed to provide stable and reliable 24 V DC output for automation, control, and process systems. Engineered for continuous operation in demanding industrial environments, it converts a wide range of AC or DC input voltages into a regulated DC power source, ensuring consistent performance of connected equipment.
Featuring a compact and robust design, the SD812F is suitable for use in ABB automation platforms and other industrial control applications requiring dependable power distribution. Its wide input voltage capability and high power output make it an ideal solution for critical systems where operational continuity and power stability are essential.
AC/DC Power Conversion
Converts wide-range AC or DC input voltage into a stable 24 V DC output for industrial equipment.
Power Distribution Support
Supplies regulated power to controllers, I/O modules, communication devices, and other automation components.
Voltage Regulation
Maintains consistent output voltage to ensure reliable operation of connected systems.
High-Current Power Delivery
Provides up to 10 A output current for demanding industrial applications.
System Protection Support
Helps stabilize power delivery and protect sensitive automation equipment from input voltage variations.
Continuous Operation Capability
Supports uninterrupted power supply for mission-critical industrial processes and control systems.
Industrial System Integration
Integrates seamlessly into ABB automation architectures and industrial control cabinets.
Compared to other industrial power supply modules with similar functionality, the ABB SD812F 3BDH000014R1 offers a broader input voltage range, higher output capacity, and superior environmental durability. These advantages make it an excellent choice for industrial automation systems requiring reliable, efficient, and continuous power delivery under demanding operating conditions.
The ABB SD812F 3BDH000014R1 Power Supply Module delivers efficient and stable power conversion with a rated output of 240 W and a maximum current capacity of 10 A. Its wide AC and DC input ranges allow it to maintain reliable operation across varying power infrastructures while providing consistent 24 V DC output to connected equipment. The module is optimized for continuous industrial use, ensuring dependable performance even under fluctuating environmental conditions. With its combination of high power density, robust thermal performance, and reliable voltage regulation, the SD812F enhances overall system efficiency, minimizes downtime, and supports long-term operational stability in industrial automation applications.
