Product Name: Power Supply Module
Brand Name: ABB
Model Number: SD822 3BSC610038R1
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Product Name | ABB SD822 3BSC610038R1 Power Supply Module |
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Part Number | SD822 3BSC610038R1 |
| Weight | 0.6 kg |
| Estimated shipping dimensions | 6.3x10.5x13.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Input Voltage | 115 / 230 V AC (switch selectable) |
| Input Voltage Type | AC |
| Max Input Current | 15 A |
| Output Voltage | 24 V DC |
| Max Output Current | 5 A |
| Number of Outputs | 1 |
| Output Power | 120 W |
| Redundancy Support | Yes (requires SS822 Voting Unit) |
| Mounting Type | DIN rail |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
Reliable 24 VDC Power Supply
Provides stable and regulated 24 VDC output to ensure consistent operation of ABB controllers, I/O modules, and other industrial automation equipment.
Supports Redundant Power Systems
Designed to operate with the ABB SS822 Voting Unit, enabling redundant power supply configurations that improve system availability and minimize unplanned downtime.
Flexible AC Input Selection
Features switch-selectable 115 VAC or 230 VAC input, allowing easy adaptation to different industrial power distribution systems.
Compact DIN-Rail Installation
The DIN-rail mounting design enables fast installation, efficient panel utilization, and convenient replacement during routine maintenance.
High-Power Industrial Performance
Delivers up to 120 W of output power with a single 24 VDC output, making it suitable for demanding automation applications requiring dependable power delivery.
Ideal for ABB Automation Systems
Widely used in ABB distributed control systems, process automation, manufacturing, power generation, water treatment, and other industrial applications requiring reliable DC power distribution.
Q1: What is the SD822 3BSC610038R1 used for?
A: The SD822 3BSC610038R1 is a power supply module that provides regulated 24 VDC power for ABB industrial automation and control systems.
Q2: Does the SD822 3BSC610038R1 support redundant power configurations?
A: Yes. The SD822 3BSC610038R1 supports redundant power operation when used together with the ABB SS822 Voting Unit.
Q3: What input voltage does the SD822 3BSC610038R1 accept?
A: The SD822 3BSC610038R1 features a switch-selectable 115 VAC or 230 VAC input to accommodate different industrial power supplies.
Q4: How is the SD822 3BSC610038R1 installed?
A: The SD822 3BSC610038R1 is designed for DIN-rail mounting, allowing quick installation and efficient integration into industrial control cabinets.
Q5: What is the output capacity of the SD822 3BSC610038R1?
A: The SD822 3BSC610038R1 delivers a regulated 24 VDC output with a maximum output current of 5 A and a rated output power of 120 W.
Q6: Which industrial applications commonly use the SD822 3BSC610038R1?
A: The SD822 3BSC610038R1 is widely used in process automation, power generation, manufacturing, water treatment, distributed control systems, and other industrial applications requiring reliable DC power supplies.
