Product Name: Servo Drive
Brand Name: Metronix
Model Number: ARS-2102 ARS2102
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Alternative Name
Metronix ARS2102 AC Servo Drive
ARS 2000 Series Intelligent Servo Controller
Industrial Motion Control Servo Drive (ARS-2102)
Multi-Axis Servo Inverter Drive
High-Precision AC Servo Motor Controller
The ARS2102 is a high-performance AC servo drive from the Metronix ARS 2000 series, designed for precise motion control in industrial automation systems. It supports synchronous, linear, and torque motors, making it suitable for robotics, packaging machinery, AGV systems, and multi-axis automation applications.
The drive combines intelligent inverter technology with flexible parameterization, enabling point-to-point positioning, master-slave synchronization, and coordinated multi-axis motion control. Its compact structure allows several ARS2102 units to be mounted directly side by side, optimizing cabinet space and simplifying installation.
The ARS2102 supports a wide range of encoder systems, including incremental encoders, resolvers, HIPERFACE, EnDat, Stegmann, and Heidenhain encoders. Integrated communication interfaces and optional fieldbus modules such as PROFIBUS-DP, SERCOS, and Ethernet provide seamless integration into industrial PLC and automation networks.
Designed for demanding industrial environments, the drive operates from −25 °C to +70 °C with up to 90% non-condensing humidity. Features such as integrated brake chopper, configurable I/O, LED diagnostics, and ServoCommander™ commissioning software ensure reliable and efficient operation.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Metronix ARS-2102 ARS2102 Servo Drive |
| Manufacturer | Metronix |
| Product Type | Servo Drive |
| Part Number | ARS-2102 ARS2102 |
| Dimensions | 5.3x21.2x23.8cm |
| Weight | 2.1kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Product Type | ARS 2102,ARS-2102 |
| Supply voltage | 1~ 100...230 V AC [± 10%] |
| DC-supply voltage | 60...380 V DC |
| Control voltage | 24 V DC [± 20%] |
| DC-link voltage | 360...380 V DC |
| Clock frequency | Variable clock frequency up to 13 kHz; Data for operation at 1~ 230 V AC, 50 Hz |
| Rated power | 0.5 kW |
| Maximum power up to 5 s | 1.0 kW |
| Rated current | 2.5 Aeff |
| Peak current up to 5 s | 5 Aeff |
| Internal brake resistor | 165 Ω |
| Rated / pulse power | 10 W / 1.1 kW |
| External brake resistor | ≥ 100 Ω |
| Max. rated brake power | ≤ 250 W |
| Brake | 24 V DC, max. 1 A |
| Storage temperature | -25 °C to +70 °C |
| Atmospheric humidity | Rel. humidity up to 90 %, non-condensing |
| Type of protection | IP20 |
Q1: Is ARS2102 suitable for multi-axis systems?
A1: Yes, the ARS2102 features a compact design that allows multiple units to be installed directly together for multi-axis control applications.
Q2: What motor types are supported by ARS2102?
A2: The ARS2102 supports synchronous motors, linear motors, and torque motors.
Q3: What is the rated power of ARS2102?
A3: The ARS2102 provides a rated power output of 0.5 kW with peak capability up to 1.0 kW for 5 seconds.
Q4: What encoder types are compatible with ARS2102?
A4: The ARS2102 supports resolvers, incremental encoders, HIPERFACE, EnDat, Stegmann, and Heidenhain encoder systems.
Q5: Does ARS2102 support industrial communication networks?
A5: Yes, the ARS2102 supports CAN communication and optional PROFIBUS-DP, SERCOS, and Ethernet fieldbus modules.
Q6: What environmental conditions can ARS2102 operate in?
A6: The ARS2102 operates in temperatures from −25 °C to +70 °C with up to 90% non-condensing humidity.
Q7: Does ARS2102 include braking functions?
A7: Yes, the ARS2102 includes an integrated brake chopper and supports both internal and external brake resistors.
