ABB TC630 3BSE002253R1 TC630 AF 100 Optical Modem Original new

ABB TC630 3BSE002253R1 TC630 AF 100 Optical Modem Original new

Product Name:TC630 AF 100 Optical Modem

Brand Name:ABB

Model Number:3BSE002253R1 TC630

Country of Origin:SWEDEN

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

abb tc630 3bse002253r1 tc630 af 100 optical modem original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	ABB
Model Number:	3BSE002253R1 TC630
Country of Origin:	SWEDEN
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Product Name	TC630 AF100 Optical Modem
Product ID	3BSE002253R1
Manufacturer	ABB
Series	Advant Fieldbus 100
Function Type	Optical / Coaxial Communication Module
Power Supply	24V DC
Fiber Type	2 × 65.5/125 µm or 100/400 µm
Connector Type	ST-style
Dimensions (D × H × W)	47 mm × 11 mm × 65 mm
Net Weight	0.715 kg

Description

TC630 3BSE002253R1 is an Advant Fieldbus 100 optical modem developed for reliable industrial communication in distributed control systems. Designed within the ABB Advant Master Process Control System, this module enables stable data transmission between coaxial and optical fiber networks, ensuring robust performance in mission-critical automation environments.

The TC630 supports both optical-to-coaxial and coaxial-to-optical conversion, making it highly flexible for hybrid network architectures. It operates on a 24V DC power supply and is compatible with ST-style fiber optic connectors, supporting 2 x 65.5/125 µm or 100/400 µm optical fiber configurations.

With compact industrial-grade construction and high resistance to electromagnetic interference, the 3BSE002253R1 TC630 ensures secure, noise-immune communication across long distances in complex process control systems.

Applications

Power plants: Generator monitoring, protection relay communication
Substations: Bus differential protection, signal transmission, switchyard control
Chemical plants: Process automation and safe signal monitoring
Steel & metallurgy: High-EMI industrial control systems
Machinery manufacturing: Robotics, packaging, and automated production lines

Features

Supports optical ↔ coaxial signal conversion
Industrial-grade EMC resistance design
Compatible with Advant Fieldbus 100 systems
Stable long-distance communication performance
ST-type fiber optic interface
Compact modular structure for easy installation

Functions

Converts and relays fieldbus communication signals
Ensures noise-free optical data transmission
Supports distributed control system networking
Enhances signal integrity in harsh environments
Provides reliable integration within ABB Advant systems

FAQ

Q1: What is TC630 3BSE002253R1 used for?
A1: It is used as an optical modem for Advant Fieldbus 100 systems to enable stable industrial data communication.

Q2: Does TC630 support fiber optic connections?
A2: Yes, it supports ST-style optical fiber connections with 65.5/125 µm and 100/400 µm compatibility.

Q3: What voltage does TC630 require?
A3: The module operates on a standard 24V DC power supply.

Q4: Is TC630 suitable for harsh industrial environments?
A4: Yes, it is designed for high EMI resistance and reliable performance in demanding industrial conditions.

Q5: Which system is TC630 compatible with?
A5: It is fully compatible with the ABB Advant Master Process Control and Advant Fieldbus 100 systems.
