Product Name: Compact Module Termination Unit
Brand Name: ABB
Model Number: TU812V1 3BSE013232R1
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB TU812V1 3BSE013232R1 Compact Module Termination Unit |
| Manufacturer | ABB |
| Product Type | Compact Module Termination Unit |
| Part Number | TU812V1 3BSE013232R1 |
| Estimated shipping dimensions | 16.8x6.5x4.5cm |
| Weight | 0.16kg |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Channels | 8 |
| Voltage | 24 V DC |
| Current | 0.5 A per channel |
| Isolation | 1500 V AC |
| Mounting | DIN Rail |
| Temperature | -20 to +60°C |
| Standards | CE, UL, RoHS |
| Voltage Rating | 50 V |
| Connector Type | D-SUB connector |
The ABB TU812V1 3BSE013232R1 is a compact industrial termination interface designed to connect field wiring with control system I/O modules. It provides a reliable and organized connection point for signal distribution in automation and process control systems.
The unit supports 8 channels with 24 V DC operation and is equipped with D-SUB connectors for secure and structured wiring. Its compact design allows efficient use of cabinet space while maintaining stable electrical performance for industrial applications.
With 1500 V AC isolation and compliance with CE, UL, and RoHS standards, the TU812V1 ensures safe and reliable operation in modern automation environments.
Compact Space-Saving Design
The ABB TU812V1 3BSE013232R1 features a compact form factor that optimizes control cabinet space usage.
Strong Electrical Isolation
With 1500 V AC isolation, it ensures high safety and protection against electrical disturbances.
Reliable 24 V DC Operation
Supports standard 24 V DC industrial voltage with stable per-channel current handling of 0.5 A.
Easy DIN Rail Installation
Designed for DIN rail mounting, it enables fast and convenient installation in industrial cabinets.
Standard Compliance
Certified with CE, UL, and RoHS, ensuring safety and environmental compliance.
Improved Wiring Organization
D-SUB connector design allows structured and reliable wiring for easier maintenance and troubleshooting.
The ABB TU812V1 3BSE013232R1 delivers stable and efficient signal termination for industrial automation systems. Its 8-channel architecture ensures organized signal distribution between field devices and I/O modules, reducing wiring complexity and improving system reliability.
The unit enhances operational safety and efficiency through 1500 V AC electrical isolation, which protects control systems from voltage disturbances and electrical noise. This improves long-term stability and reduces maintenance requirements in industrial environments.
Designed for compact and efficient installation, the TU812V1 supports DIN rail mounting and operates reliably within a temperature range of -20°C to +60°C. Its optimized design ensures consistent performance while minimizing space usage in control cabinets.
1. What type of connector is used in the TU812V1 3BSE013232R1?
The TU812V1 3BSE013232R1 uses D-SUB connectors for wiring connections.
2. How many channels does the TU812V1 3BSE013232R1 support?
The TU812V1 3BSE013232R1 supports 8 signal channels.
3. What is the operating voltage of the TU812V1 3BSE013232R1?
The TU812V1 3BSE013232R1 operates at 24 V DC.
4. What type of mounting does the TU812V1 3BSE013232R1 use?
The TU812V1 3BSE013232R1 is designed for DIN rail mounting.
5. What level of electrical isolation does the TU812V1 3BSE013232R1 provide?
The TU812V1 3BSE013232R1 provides 1500 V AC isolation between field and system circuits.
6. What is the operating temperature range of the TU812V1 3BSE013232R1?
The TU812V1 3BSE013232R1 operates from -20°C to +60°C.
