Allen-Bradley 1394C-AM04 1394C SERCOS axis module Ready For Ship

Allen-Bradley 1394C-AM04 1394C SERCOS axis module Ready For Ship

Product Name:1394C SERCOS axis module

Brand Name:Allen-Bradley

Model Number:1394C-AM04

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1394c am04 1394c sercos axis module ready for ship-1

Overview
Inquiry now
Specifications
Description
Applications
Environment and Certification
High-Resolution Measurement
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1394C-AM04
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	1394C-AM04 SERCOS axis module designed for Allen-Bradley 1394 Integrated Motion Control systems.
Product Type:	Multi-axis servo control module providing deterministic motion control through SERCOS fiber-optic communication.
Communication Interface:	Dual SERCOS fiber-optic Tx/Rx connectors supporting closed-loop ring network architecture.
Supported Communication Speed:	Configurable SERCOS baud rates of 2 Mbps, 4 Mbps, and 8 Mbps via onboard DIP switches.
System Compatibility:	Compatible with ControlLogix, SoftLogix, 1756-MxxSE SERCOS interface modules, and 1784-PM16SE PCI cards.
Configuration Features:	Supports configurable base node addressing, optical power level selection, and multi-system SERCOS ring topology.
Fiber-Optic Cable Support:	Supports plastic fiber cables up to 32 m and glass fiber cables up to 200 m.
Dimension:	Standard Allen-Bradley 1394C axis module dimensions (refer to official installation documentation).
Weight:	Manufacturer weight specification is not provided in the available documentation.

Description

1394C-AM04 is an Allen-Bradley 1394C SERCOS axis module engineered for high-performance multi-axis motion control applications. Designed to operate within the 1394 Integrated Motion Control System, it communicates through the SERCOS fiber-optic interface, enabling deterministic real-time motion synchronization between controllers and servo drives. The module is compatible with 1394C-AM03, 1394C-AM04, 1394C-AM07, and larger 1394C-AM50 and 1394C-AM75 series configurations.

Built for demanding industrial automation, 1394C-AM04 supports configurable node addressing, selectable SERCOS transmission speeds up to 8 Mbps, and high optical power settings for stable fiber-optic communication. Integration with ControlLogix®, SoftLogix®, 1756-MxxSE, and 1784-PM16SE platforms simplifies commissioning and motion system expansion.

With reliable SERCOS connectivity, flexible network configuration, and advanced motion control capabilities, 1394C-AM04 is an ideal solution for precision servo control, synchronized multi-axis machinery, robotics, packaging equipment, and high-speed manufacturing systems.

Applications

Power plants: Provides synchronized servo motion control for turbine auxiliary systems, positioning equipment, and automated maintenance machinery.
Substations: Controls precision positioning systems and automated equipment requiring deterministic fiber-optic communication.
Chemical plants: Coordinates multi-axis process machinery, filling systems, and automated material handling equipment.
Steel mills: Delivers synchronized motion control for rolling mills, coil handling systems, and heavy-duty production machinery.
Machinery manufacturing plants: Operates robotic workstations, CNC equipment, packaging machinery, and automated assembly systems with high-speed servo synchronization.
Semiconductor and electronics manufacturing: Supports high-precision motion control applications requiring accurate positioning and stable SERCOS communication.

Environment and Certification

Designed for industrial automation and precision motion control environments.
Supports reliable operation through fiber-optic communication with excellent electromagnetic interference immunity.
Compatible with Allen-Bradley integrated motion control architecture for long-term industrial deployment.
Supports high optical transmission power for extended communication reliability.
Engineered for deterministic real-time motion control in demanding production environments.
Suitable for high-speed industrial machinery requiring continuous synchronized operation.

High-Resolution Measurement

Supports deterministic SERCOS motion communication with configurable speeds up to 8 Mbps.
High-speed data exchange improves servo positioning accuracy and motion synchronization.
Fiber-optic transmission minimizes communication latency and signal interference.
Precise node addressing enables accurate multi-axis coordination.
Stable communication architecture improves repeatability in complex motion applications.
Optimized for high-performance servo systems requiring precise speed, position, and synchronization control.

FAQ

Q1: What is 1394C-AM04 used for?
A1: 1394C-AM04 is a SERCOS axis module used for synchronized multi-axis servo motion control in Allen-Bradley 1394 Integrated Motion Control systems.

Q2: Which communication protocol does 1394C-AM04 support?
A2: The module communicates through the SERCOS fiber-optic interface, providing deterministic real-time motion control for industrial automation.

Q3: What baud rates are available on 1394C-AM04?
A3: The module supports configurable 2 Mbps, 4 Mbps, and 8 Mbps SERCOS communication speeds using onboard DIP switch settings.

Q4: Which controllers are compatible with 1394C-AM04?
A4: It integrates with Allen-Bradley ControlLogix®, SoftLogix®, 1756-MxxSE SERCOS interface modules, and 1784-PM16SE PCI interface cards.

Q5: What fiber-optic cable types can be used with 1394C-AM04?
A5: 1394C-AM04 supports plastic fiber-optic cables up to 32 meters and glass fiber-optic cables up to 200 meters, providing flexible installation options for industrial motion control networks.
