Product Name:ControlLogix Terminal Block 36 Pin Screw Clamp
Brand Name:Allen Bradley
Model Number:1756-TBCH
Country of Origin:Mexico
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Allen Bradley |
Model Number: |
1756-TBCH |
Country of Origin: |
Mexico |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 1756-TBCH |
| Product Type | ControlLogix Terminal Block |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Series | ControlLogix 1756 / 1757 |
| Pin Configuration | 36-Pin |
| Terminal Type | Screw Clamp / Cage Clamp |
| Mounting Style | Removable Terminal Block |
| Application Interface | PLC I/O Field Wiring Connection |
| Compatible System | ControlLogix I/O Modules |
| Material | Industrial-Grade Insulated Housing |
| Electrical Rating | Standard Industrial Signal Interface |
| Wiring Capacity | Multi-conductor field wiring support |
| Dimensions (Approx.) | 145 × 35 × 90 mm (5.71 × 1.38 × 3.54 in.) |
| Weight (Approx.) | 0.28 kg (0.62 lb) |
| Installation Position | ControlLogix I/O Chassis Front Interface |
| Operating Environment | Industrial Control Panels |
1756-TBCH is a 36-pin screw clamp terminal block designed for use within Rockwell Automation ControlLogix I/O systems. It provides a reliable and structured wiring interface between field devices and ControlLogix I/O modules, ensuring stable signal transmission and secure electrical connections in industrial automation environments.
Engineered for compatibility with the ControlLogix 1756 platform, 1756-TBCH supports streamlined installation and simplified maintenance of I/O wiring assemblies. It is commonly used in combination with 1756-series I/O modules to enhance wiring organization and reduce commissioning time in complex control systems.
Alongside related terminal block variants within the ControlLogix accessory range, 1756-TBCH helps maintain consistent panel design, improved wiring safety, and efficient system expansion for modern industrial automation applications.
Power Plants: Used for generator monitoring systems, turbine control wiring, and relay protection signal connections.
Substations: Supports bus differential protection wiring, switchgear control, and SCADA signal interfacing.
Chemical Plants: Enables safe and organized wiring for process automation and intrinsically safe control circuits.
Steel Mills: Provides stable signal termination in high-temperature and high-interference industrial environments.
Machinery Manufacturing Plants: Used in automated production lines, robotic systems, and packaging machine control wiring.
Oil & Gas Facilities: Supports distributed control systems and field device signal integration in harsh environments.
Water Treatment Plants: Used for pump control wiring, instrumentation connection, and process monitoring systems.
Q1: What is the function of the 1756-TBCH terminal block?
A1: It provides a secure wiring interface between field devices and ControlLogix I/O modules.
Q2: How many pins does the 1756-TBCH have?
A2: The module features a 36-pin screw clamp configuration.
Q3: Is the 1756-TBCH compatible with all ControlLogix systems?
A3: It is designed for use with ControlLogix 1756 I/O modules and compatible chassis systems.
Q4: Does the 1756-TBCH support removable installation?
A4: Yes, it is designed as a removable terminal block for easier maintenance.
Q5: Where is the 1756-TBCH commonly used?
A5: It is widely used in power plants, substations, chemical plants, and industrial automation systems.
|
