Product Name:Digital Input 24VDC
Brand Name:Honeywell
Model Number:8C-TDILA1 51307141-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-TDILA1 51307141-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
8C-TDILA1 / 51307141-175 |
|
Type |
Digital Input Sequence of Events (SOE) |
|
Channels |
32 inputs |
|
Voltage |
24 VDC |
|
Scan Modes |
20ms Normal / 5ms Fast / 1ms SOE |
|
SOE Resolution |
1 ms time tagging |
|
Isolation |
1000 VAC RMS optical isolation |
|
Input Range |
18–30 VDC |
|
Module Current |
95 mA |
|
Temperature |
0°C to 60°C operating |
|
Storage Temp |
-40°C to 85°C |
|
Dimension |
12x6.2x22.2cm |
|
Weight |
0.36kg |
The 8C-TDILA1 51307141-175 Digital Input Sequence of Events module is designed for high-speed 24VDC signal acquisition within Honeywell Series 8 automation and C300 control systems. It supports precise event capturing with time-tagging capability, making it suitable for critical monitoring and protection applications.
Built on advanced Series 8 architecture, the 8C-TDILA1 provides 32-channel input processing with flexible scanning modes including Normal, Fast, and Sequence of Events operation. Its modular IOTA-based design simplifies installation while ensuring stable signal acquisition and reduced wiring complexity.
The 8C-TDILA1 51307141-175 delivers high reliability through optical isolation, integrated diagnostics, and optional redundancy support. It is widely used in industrial automation environments requiring fast response, accurate event sequencing, and secure digital input processing.
Q1: What is the main function of 8C-TDILA1?
A1: It provides 32-channel 24VDC digital input with 1ms sequence-of-events time stamping.
Q2: What scanning modes are available?
A2: Normal (20ms), Fast (5ms), and SOE mode with 1ms resolution.
Q3: Does it support redundancy?
A3: Yes, redundancy is optional depending on system configuration.
Q4: What type of signals does it accept?
A4: It accepts standard 24VDC discrete industrial input signals.
Q5: Is it suitable for harsh environments?
A5: Yes, it supports industrial-grade isolation and temperature tolerance.
| Number | Describe |
|---|---|
| 8C-TAIMA1 / 8U-TAIMA1 | TC/RTD IOTA module, coated or uncoated version, designed for thermocouple and RTD signal acquisition, 16-channel support, 9-inch IOTA platform for Series 8 system integration |
| 8C-TAIXA1 / 8U-TAIXA1 | Analog input single-ended IOTA module, 16-channel, 6-inch size, supports standard analog signal processing for Series 8 control systems |
| 8C-TAIDA1 / 8U-TAIDA1 | Analog input differential IOTA module, 16-channel, 9-inch configuration, optimized for stable multi-signal acquisition in industrial environments |
| 8C-TAIXB1 / 8U-TAIXB1 | Redundant single-ended analog input IOTA module, 16-channel, 12-inch design, enhanced reliability for critical process control applications |
| 8C-TAIDB1 / 8U-TAIDB1 | Redundant differential analog input IOTA module, 16-channel, 12-inch structure, designed for high-availability industrial automation systems |
| 8C-TAOXA1 / 8U-TAOXA1 | Analog output IOTA module, 16-channel, 6-inch format, supports precise 4–20mA output control for process regulation |
| 8C-TAOXB1 / 8U-TAOXB1 | Redundant analog output IOTA module, 16-channel, 12-inch configuration, built for high-reliability output control systems |
| 8C-TDILA1 / 8U-TDILA1 | Digital input 24VDC IOTA module, 32-channel, 9-inch design, coated or uncoated version for industrial signal acquisition |
| 8C-TDILB1 / 8U-TDILB1 | Redundant digital input 24VDC IOTA module, 32-channel, 12-inch structure, high-availability input solution for Series 8 systems |
| 8C-TDODA1 / 8U-TDODA1 | Digital output IOTA module, 32-channel, 9-inch format, standard 24VDC output control for industrial automation systems |
| 8C-TDODB1 / 8U-TDODB1 | Redundant digital output IOTA module, 32-channel, 12-inch design, high-reliability output module for critical control applications |
