Product Name:versatile remote termination panel
Brand Name:Allen-Bradley
Model Number:1771-RTP4
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Allen-Bradley |
Model Number: |
1771-RTP4 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 1771-RTP4 |
| Product Type | Remote Termination Panel |
| Manufacturer | Allen-Bradley |
| Compatible Series | 1771-N Series Analog I/O Modules |
| Mounting Method | DIN 1 or DIN 3 Rail Mounting |
| Wiring Type | Straight-Through Wiring |
| Supported Signals | Voltage, Current, RTD, and Analog Signals |
| Compatible Cables | 1771-NC6 (6 ft), 1771-NC15 (15 ft) |
| Thermocouple Support | Requires External Cold Junction Compensation |
| Installation Purpose | Field Signal Termination and Distribution |
| Connection Method | Remote Interface Connection |
| Application Environment | Industrial Automation Systems |
| Dimensions (Approx.) | 210 × 120 × 45 mm |
| Weight (Approx.) | 0.45 kg |
| Maintenance Access | Front Accessible Terminal Design |
| Signal Isolation Support | Dependent on Connected Analog Module |
| Housing Material | Industrial-Grade Terminal Assembly |
1771-RTP4 is a versatile remote termination panel developed for seamless integration with Allen-Bradley 1771-N Series high-resolution analog I/O modules. Designed to simplify field wiring and signal termination, it provides a reliable interface between analog modules and process instruments while supporting a wide range of industrial automation applications. Its straight-through wiring architecture allows efficient signal transmission without additional conditioning components.
Working alongside modules such as 1771-NIS, 1771-NIV, 1771-NIVR, 1771-NIVT, 1771-NOC, and 1771-NOV, the 1771-RTP4 helps streamline installation and maintenance procedures. The panel mounts directly on standard DIN rails and connects to I/O modules through dedicated interface cables, reducing wiring complexity and improving system organization.
Engineered for industrial environments, 1771-RTP4 offers dependable signal routing, flexible application support, and simplified field connections, making it an ideal solution for process control, manufacturing automation, and plant-wide monitoring systems.
Q1: What is the primary purpose of the 1771-RTP4?
A1: It serves as a remote termination panel for connecting field devices to 1771-N Series analog I/O modules.
Q2: Which Allen-Bradley modules are compatible with the 1771-RTP4?
A2: It is compatible with several 1771-N Series modules, including 1771-NIS, 1771-NIV, 1771-NOC, and related models.
Q3: Can the 1771-RTP4 be used with thermocouple applications?
A3: Yes, but an external method of cold junction compensation is required.
Q4: How is the 1771-RTP4 mounted?
A4: The panel is designed for installation on standard DIN 1 or DIN 3 mounting rails.
Q5: What cables are typically used with the 1771-RTP4?
A5: The panel commonly uses 1771-NC6 (6 ft) or 1771-NC15 (15 ft) interface cables.
