Allen-Bradley 1783-LMS8 industrial Ethernet switching solution Original new

Allen-Bradley 1783-LMS8 industrial Ethernet switching solution Original new

Product Name:industrial Ethernet switching solution

Brand Name:Allen-Bradley

Model Number:1783-LMS8

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1783 lms8 industrial ethernet switching solution original new -1

Overview
How to get price
Specifications
Description
Applications
Control & Communication
Environment & Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1783-LMS8
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

How to get price

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	1783-LMS8, managed industrial Ethernet switch module for Stratix 2500 system with 8-port network control capability
Port Configuration	8 Fast Ethernet ports, structured for independent monitoring and control of each communication channel
Data Structure	Input/Output tags mapped in Studio 5000 Logix Designer, enabling PLC-based network diagnostics and control
Communication Protocol	CIP-based Ethernet communication, supporting real-time industrial data exchange and device integration
Port Control Function	Per-port enable/disable via output bits, allowing controller-driven network segmentation and protection
Diagnostics Features	Link status, unauthorized device detection, utilization monitoring, and threshold alarm reporting
Network Interface	10/100 Mbps Ethernet switching architecture for deterministic industrial communication
Installation Type	PLC-mounted rack module for ControlLogix-based automation systems
Dimensions	Width: 482 mm, integrated rack-based industrial mounting structure
Dimensions	Height: 158 mm, designed for standardized control cabinet installation
Dimensions	Depth: 145 mm, compact depth for panel integration
Weight	Approx. 2–3 kg (industrial rack module configuration)

Description

The 1783-LMS8 is an industrial Ethernet switching solution designed for reliable multi-port network control in automation environments. It provides structured input and output data handling through Studio 5000 Logix Designer, enabling precise port-level monitoring and control.

The system supports up to eight Fast Ethernet ports with detailed diagnostics such as link status, utilization, threshold alerts, and unauthorized device detection. Each port can be independently enabled or disabled via controller output tags, ensuring flexible network segmentation and security enforcement.

Engineered for integration within 1783-LMS5 and 8-port architectures, the module ensures deterministic communication, seamless CIP data mapping, and robust industrial network performance for mission-critical automation systems.
