Product Name: Eddy Current Signal Converter
Brand Name: EMERSON
Model Number: PR6423/00R-131 CON041
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Non-Contact Displacement Measurement | Axial Position Measurement |
| Vibration Monitoring System | Turbine Monitoring System |
| Emerson EPRO Converter | Compressor Protection Module |
| Rotating Machinery Monitoring | Generator Condition Monitoring |
| Industrial Signal Converter | High-Precision Signal Processing |
| Shaft Displacement Monitoring | Machinery Fault Diagnosis |
| Predictive Maintenance Solution | Eddy Current Measurement System |
| Industrial Automation Module | DCS Compatible Converter |
| Radial Vibration Monitoring | Real-Time Condition Monitoring |
| Industrial Diagnostic Equipment |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | EMERSON PR6423/00R-131 CON041 Eddy Current Signal Converter |
| Manufacturer | EMERSON |
| Product Type | Eddy Current Signal Converter |
| Part Number | PR6423/00R-131 CON041 |
| Estimated shipping dimensions | 16x16x2cm |
| Weight | 0.22kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) ISO | 8 V/mm (203.2 mV/mil) ± 5% @ temperature range 0 to 45°C (+32 to +113°F) |
| Deviation from best fit straight line (DSL) | ± 0.025 mm (± 1 mil) @ temperature range 0 to 45°C (+32 to +113°F) |
| Minimum Shaft Diameter | 25 mm (0.79”) |
| Target Material (Ferromagnetic Steel) | 42CrMo4 (AISI/SAE 4140) Standard Other (On Request) |
The Emerson PR6423/00R-131 CON041 Eddy Current Signal Converter is a high-performance industrial monitoring device designed for precise non-contact displacement and vibration measurement in rotating machinery applications. Combined with the PR6423 eddy current sensor, the CON041 signal converter provides accurate and stable monitoring of radial and axial shaft movements for predictive maintenance and machinery protection systems.
Using advanced eddy current technology, the converter enables continuous real-time monitoring of industrial equipment such as turbines, compressors, generators, and pumps. Its rugged industrial design ensures reliable operation in demanding environments while supporting high-accuracy diagnostics and fault detection.
System Configuration
The PR6423/00R-131 CON041 signal converter is designed for integration with Emerson EPRO monitoring systems, Distributed Control Systems (DCS), and industrial machinery protection platforms. It supports continuous condition monitoring of rotating equipment in critical industrial applications.
Measurement Configuration
The converter provides a linear measurement range of 2 mm with an initial air gap of 0.5 mm. This configuration enables precise non-contact monitoring of shaft displacement and vibration in rotating machinery systems.
Signal Processing Configuration
The module features an Incremental Scale Factor (ISF) of 8 V/mm ±5% and maintains high measurement accuracy with minimal deviation from the best fit straight line. This ensures reliable signal conversion and stable monitoring performance.
Mechanical Configuration
The system is designed for applications with a minimum shaft diameter of 25 mm and is optimized for ferromagnetic steel target materials such as 42CrMo4 (AISI/SAE 4140). This allows accurate and stable displacement measurements in industrial rotating equipment.
Alarm & Predictive Maintenance Programming
The converter supports machinery condition monitoring and predictive maintenance applications by continuously processing displacement and vibration signals. Early detection of abnormal shaft movement helps reduce downtime and improve equipment reliability.
