Allen-Bradley 1783-MX08T Wired Network Copper Expansion Module

Allen-Bradley 1783-MX08T Wired Network Copper Expansion Module

Product Name: Wired Network Copper Expansion Module

Brand Name: Allen-Bradley

Model Number: 1783-MX08T

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

allen bradley 1783 mx08t wired network copper expansion module-1

Overview
Contact Us
Specifications
Description
Functions
Advantage
Why Choose US
Other Products
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
*Jim Pei*	*[email protected]*	*+86 18020776782*

Specifications

Product Name	Allen-Bradley 1783-MX08T Wired Network Copper Expansion Module
Manufacturer	Allen-Bradley
Product Type	Wired Network Copper Expansion Module
Part Number	1783-MX08T
Weight	0.92kg
Estimated shipping dimensions	10x11.8x17.4cm
Place of shipment	Xiamen, China
Country of origin	USA
Switch input rating, max	0.3A @ 12V DC
Power dissipation	2.8 W
Temperature, operating	-40…60 °C (-40…140 °F)
Temperature, surrounding air, max	60 °C (140 °F)
Temperature, nonoperating	-40…85 °C (-40…185 °F)
Relative humidity	5…95% noncondensing
Vibration	2 g @ 10…500 Hz
Oscillatory surge withstand	2.5 kV
Magnetic field immunity	30 A/m long duration and 300 A/m short duration at 50 and 60 Hz
Conducted RF immunity	10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Isolation Voltage	75V (Continuous), Basic Insulation Type (Backplane to Network)
Dielectric Type Test	1000V AC for 60 seconds
Inter-port Isolation	None (Shared Common Network Shield)
Total Ports Count	8 Ports
Ethernet Port Type	10/100Base-TX (RJ-45 Connectivity)
Backplane Input Voltage	3.3V DC via Stratix Base Backplane
Backplane Current (Max)	1.7 A

Description

The Allen-Bradley 1783-MX08T Wired Network Copper Expansion Module is an 8-port industrial Ethernet expansion module designed to increase network connectivity for Stratix-based managed Ethernet switch systems. Featuring eight 10/100Base-TX RJ-45 copper ports, it enables the connection of additional PLCs, HMIs, drives, I/O devices, and other industrial Ethernet equipment within automation networks. Designed for seamless backplane integration, the module provides reliable network expansion while maintaining stable performance in demanding industrial environments.

Functions

Expands industrial Ethernet networks with eight additional copper ports.

Connects PLCs, HMIs, drives, I/O modules, and other Ethernet-enabled devices.

Supports 10/100Base-TX Ethernet communication through RJ-45 interfaces.

Integrates with compatible Stratix Ethernet switch platforms via the backplane.

Enables flexible network expansion without replacing the existing switch.

Provides reliable industrial network communication for automation systems.

Supports continuous operation in harsh industrial environments.

Advantage

Compared with conventional Ethernet expansion modules, the Allen-Bradley 1783-MX08T provides seamless Stratix integration, reliable industrial performance, and flexible network scalability, making it ideal for expanding industrial Ethernet infrastructures.

Eight Additional Ethernet Ports: Adds 8 × 10/100Base-TX RJ-45 ports, allowing easy expansion of industrial Ethernet networks without additional standalone switches.
Seamless Stratix Integration: Installs directly into compatible Stratix managed switch platforms through the backplane for simplified system expansion.
Industrial-Grade Reliability: Designed to operate in harsh environments with an operating temperature range of -40°C to +60°C, high vibration resistance, and strong electromagnetic immunity.
Low Power Consumption: Consumes only 2.8 W, helping reduce overall system power requirements.
Enhanced Electrical Protection: Provides isolation between the backplane and network interfaces, contributing to stable communication in electrically noisy industrial environments.
Flexible Network Scalability: Allows automation systems to expand network capacity without significant hardware modifications, reducing installation costs and downtime.
Optimized for Rockwell Automation Networks: Fully compatible with Allen-Bradley Stratix Ethernet infrastructure, enabling reliable integration with EtherNet/IP-based control and automation systems.
