Product Name: DC-bus Power Supply
Brand Name: Allen-Bradley
Model Number: 2198-P070
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Allen-Bradley 2198-P070 DC-bus Power Supply |
| Manufacturer | Allen-Bradley |
| Product Type | DC-bus Power Supply |
| Part Number | 2198-P070 |
| Weight | 4.84kg |
| Estimated shipping dimensions | 5.8x25.3x37cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Internal Shunt Specifications | 37.5Ω |
| Supported Capacitance, max | 8,000µF |
| Internal Capacitance | 780µF |
| Capacitive Energy Absorption | 172J |
| AC input voltage | 324…528V rms, three-phase (480V nom) |
| AC input frequency | 47…63 Hz |
| Main AC input current | 27.0 A |
| Max inrush (0-pk) | 33.0 A |
| Peak AC input current | 74.3 A |
| Line loss ride through | 20 ms |
| Control power DC input voltage | 24V DC ±10% |
| Control power DC input current | 0.8 ADC |
| Nominal bus output voltage | 458…747V DC |
| Peak output current duration | 1.0 s |
| Continuous output power to bus | 17.0 kW |
| Internal shunt power | 75 W |
| Continuous output current to bus | 25.5 ADC |
| Peak output current to bus | 70.3 ADC. |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The 2198-P070 DC-bus Power Supply is a high-performance industrial power supply designed to provide stable DC bus power for multi-axis servo drive systems. Engineered for demanding automation applications, it converts three-phase AC input into a regulated DC bus voltage to support Kinetix motion control systems. Featuring high continuous output power, built-in shunt capability, and reliable energy management, the 2198-P070 helps improve system efficiency, simplify power distribution, and ensure dependable operation in high-performance industrial environments.
✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems
Q1: What is the 2198-P070 DC-bus Power Supply used for?
A: The 2198-P070 is designed to convert three-phase AC power into a regulated DC bus supply for servo drive systems, providing reliable power for industrial motion control applications.
Q2: What input voltage does the 2198-P070 support?
A: The 2198-P070 accepts 324–528 VAC RMS three-phase input power at 47–63 Hz, making it suitable for 480 V industrial power systems.
Q3: What is the continuous output power of the 2198-P070?
A: The 2198-P070 delivers up to 17.0 kW of continuous output power to the DC bus, supporting demanding multi-axis servo applications.
Q4: What is the DC bus output voltage of the 2198-P070?
A: The 2198-P070 provides a nominal DC bus output voltage ranging from 458 VDC to 747 VDC, ensuring stable power for compatible servo drives.
Q5: Does the 2198-P070 include an internal shunt resistor?
A: Yes. The 2198-P070 features a built-in 37.5 Ω internal shunt resistor with 75 W shunt power for regenerative energy dissipation.
Q6: What control power is required for the 2198-P070?
A: The 2198-P070 requires a 24 VDC (±10%) control power input with a nominal current of 0.8 ADC.
