Bently Nevada 114M5330-01 Low Voltage DC Power Supply Ready For Ship

Bently Nevada 114M5330-01 Low Voltage DC Power Supply Ready For Ship

Product Name:Low Voltage DC Power Supply

Brand Name:Bently Nevada

Model Number:114M5330-01

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 114m5330 01 low voltage dc power supply ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	114M5330-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Product Model	114M5330-01
Product Description	Low Voltage DC Power Supply Module
System Series	Bently Nevada 3500 Series
Input Voltage	20 to 30 VDC
Maximum Current Draw	11.0 A (Full Rack)
Module Type	Half-height Rack Module
Rack Compatibility	3500 Machinery Protection System
Redundancy Support	Yes, Dual Power Supply Configuration
Operating Temperature	-30°C to +65°C
Storage Temperature	-40°C to +85°C
Humidity Rating	95% Non-condensing
Dimensions (H × W × D)	120.7 × 50.8 × 251.5 mm
Weight	1.39 kg
Status Indicator	Front-panel Supply OK LED

Description

The 114M5330-01 is a reliable Low Voltage DC Power Supply Module developed for the Bently Nevada 3500 Machinery Protection System. Designed to provide stable power conversion and distribution, it supports continuous operation of monitoring and protection modules in critical industrial environments where system availability is essential.

As part of the 3500 Series platform, the 114M5330-01 efficiently converts low-voltage DC input into regulated power required by rack-mounted monitoring equipment. Compatible with associated modules such as 114M5335-01, 114M5329-01, and other 3500 system components, it helps maintain dependable power integrity throughout the protection system architecture.

The 114M5330-01 is widely deployed in power generation, oil and gas, petrochemical, and manufacturing facilities. Its rugged design, high operational reliability, and support for redundant power configurations contribute to improved equipment protection and reduced downtime.

Applications

Power Plants: Provides stable power for turbine vibration monitoring, generator protection, and machinery health management systems.
Substations: Supports continuous operation of protection and monitoring equipment within electrical distribution infrastructures.
Chemical Plants: Ensures reliable power delivery for process monitoring and critical safety systems.
Steel Mills: Maintains uninterrupted operation of machinery protection systems in high-temperature and high-EMI environments.
Machinery Manufacturing Plants: Powers monitoring racks used in automated production lines, compressors, pumps, and rotating equipment diagnostics.

Features

Wide low-voltage DC input range
Designed for Bently Nevada 3500 systems
Supports redundant power configurations
Compact half-height rack design
High reliability industrial construction
Integrated power status indication
Suitable for critical machinery protection applications

Functions

Converts low-voltage DC input into regulated system power
Supplies operating power to 3500 monitoring modules
Supports redundant rack power architecture
Enhances system availability and operational reliability
Provides power status monitoring through LED indication

FAQ

Q1: What is the primary function of the 114M5330-01?
A1: It supplies regulated low-voltage DC power to Bently Nevada 3500 monitoring and protection systems.

Q2: Which input voltage range does the 114M5330-01 support?
A2: The module operates with a DC input voltage range of 20 to 30 VDC.

Q3: Can the 114M5330-01 be used in redundant power configurations?
A3: Yes, it supports dual power supply installations for increased system reliability.

Q4: What industries commonly use the 114M5330-01?
A4: It is widely used in power generation, oil and gas, petrochemical, and manufacturing industries.

Q5: Is the 114M5330-01 compatible with the Bently Nevada 3500 Series?
A5: Yes, it is specifically designed for integration with the Bently Nevada 3500 Machinery Protection System.

Spares

Number	Describe
106M1079-01	Universal AC Power Supply Module
106M1081-01	Universal AC Power Input Module
129486-01	Legacy High Voltage DC Power Supply Module
129478-01	Legacy High Voltage DC Power Input Module
133292-01	Legacy Low Voltage DC Power Supply Module
133300-01	Legacy Low Voltage DC Power Input Module
114M5329-01	High Voltage DC Power Supply Module
115M7750-01	High Voltage DC Power Input Module (PIM)
114M5330-01	Low Voltage DC Power Supply Module
114M5335-01	Low Voltage DC Power Input Module (PIM)
01720025	Replacement fuse for AC Power Input Module and Legacy High Voltage DC Power Input Module
01720045	Replacement fuse for Low Voltage DC Power Input Module and Legacy Low Voltage DC Power Input Module
120M3877	Fast-blow replacement fuse, 5A/500 Vac, 6.3 × 32 mm, for Universal AC Power Input Module
131150-01	Power Supply Blank Front Panel, includes mounting screws
128085-01	Power Supply Rear Input Connector Cover (screws ordered separately)
04310251	Mounting screws for Power Supply Input Cover (qty 2)
129767	3500/15 Power Supply User Guide
118M0915-01	Replacement connector for Universal AC Power Input Module
118M0915-02	Replacement connector for DC Power Input Module
129M0198	Replacement fuse for High Voltage DC Power Input Module (PIM)
