Product Name: Low Voltage DC PIM
Brand Name: Bently Nevada
Model Number: 114M5335-01
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Alternative Name
Bently Nevada 3500/15 Low Voltage DC Power Input Module (PIM)
114M5335-01 DC Power Interface Module
24 V DC Rack Power Input Module for 3500 System
3500/15 Low Voltage Power Supply Interface Unit
Machinery Protection Rack DC Power Distribution Module
Industrial 24 V DC Rack Power Input Interface
3500 Series Power Input Module (Low Voltage DC)
Rack-Mounted DC Power Conditioning Module
Bently Nevada 3500/15 Power Entry Module (24 V DC)
Low Voltage DC Power Integration Module for Machinery Monitoring Systems
The 114M5335-01 Low Voltage DC Power Input Module (PIM) designed for the Bently Nevada 3500/15 rack system, providing a reliable interface for integrating external 24 V DC power into machinery protection and condition monitoring systems. It ensures stable and continuous power distribution to all rack modules, supporting critical industrial monitoring applications.
Installed at the rear-left position of the 3500/15 rack, the 114M5335-01 works in combination with the front-mounted power supply module to deliver redundant and uninterrupted system operation. When two power supplies are installed, the system enables hot-swappable maintenance without shutting down the rack, ensuring maximum availability for machinery protection functions.
Designed for harsh industrial environments, the module supports a wide operating temperature range and high humidity conditions, making it suitable for continuous operation in power plants, oil & gas facilities, and heavy industrial installations. Its compact half-height design allows efficient rack space utilization while maintaining robust electrical performance and safety.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 114M5335-01 Low Voltage DC PIM |
| Manufacturer | Bently Nevada |
| Product Type | Low Voltage DC PIM |
| Part Number | 114M5335-01 |
| Dimensions | 2.5x12x12cm |
| Weight | 0.32kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Operating temperature | -30 °C to +65 °C -22 °F to +150 °F |
| Storage temperature | -40 °C to +85 °C -40 °F to +185 °F |
| Full Rack Current Draw | 11.0 A (maximum) |
| Input Voltage | 20 to 30 Vdc |
| Input Signal | LVDT/RVDT (1-5V RMS, 2.5-10kHz) |
| Output Signal | 4-20mA (fault = 3.8mA or 21mA) |
| Accuracy | ±0.25% FS |
| Humidity | 95%, non-condensing |
Q1: Where is 114M5335-01 installed in the rack?
A2: The 114M5335-01 is installed at the rear-left side of the 3500/15 rack.
Q2: Can 114M5335-01 be hot-swapped during operation?
A2: Yes, the 114M5335-01 supports hot-swappable installation when a redundant power module is present.
Q3: What is the input voltage range of 114M5335-01?
A3: The 114M5335-01 operates with an input voltage range of 20–30 V DC.
Q4: What is the maximum rack current supported by 114M5335-01?
A4: The 114M5335-01 supports up to 11.0 A full rack current draw.
Q5: What system is 114M5335-01 used with?
A5: The 114M5335-01 is used with the Bently Nevada 3500/15 rack system.
Q6: What is the operating temperature range of 114M5335-01?
A6: The 114M5335-01 operates from -30°C to +65°C (-22°F to +150°F).
Q7: Does 114M5335-01 support redundancy?
A7: Yes, the 114M5335-01 supports redundant power configurations for continuous operation.
