Product Name:Proximitor I/O Module with External Terminations
Brand Name:Bently Nevada
Model Number:126615-01
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
126615-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | 126615-01 |
| Product Type | Proximitor I/O Module with External Terminations |
| System Compatibility | Bently Nevada 3500/40M Proximitor Monitor |
| Input Channels | 1 to 4 proximity transducer signals |
| Input Impedance | 10 kΩ standard |
| Power Consumption | 7.7 W typical |
| Sensitivity Range | 3.94 to 7.87 mV/µm depending on measurement type |
| Output Signal | Buffered transducer + 4–20 mA recorder output |
| Output Impedance | 550 Ω |
| Transducer Supply | -24 Vdc |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | Up to 95% non-condensing |
| Module Dimensions | 241.3 × 24.4 × 99.1 mm |
| Weight | 0.20 kg |
| Installation Type | Rear-mounted external termination I/O module |
| Compliance | CE, EMC, UL, ATEX/IECEx |
The 126615-01 Proximitor I/O Module with External Terminations is a key interface component for the Bently Nevada 3500/40M Proximitor Monitoring System, designed to process and condition vibration and position signals from proximity transducers. It enables accurate measurement of radial vibration, thrust position, eccentricity, and differential expansion in rotating machinery.
Integrated into the 3500 rack architecture, the 126615-01 supports four-channel signal input with flexible configuration through rack software. It works in conjunction with external termination blocks to simplify wiring and improve system scalability in industrial monitoring environments.
Built for high reliability, the module ensures stable performance in machinery protection and condition monitoring applications, making it suitable for turbines, compressors, and other critical rotating equipment systems.
Q1: What is the 126615-01 used for?
A1: It is used for processing proximity transducer signals in the Bently Nevada 3500/40M monitoring system.
Q2: How many channels does it support?
A2: It supports up to four input channels for vibration and position monitoring.
Q3: Does it support external termination?
A3: Yes, it is designed for use with external termination blocks for flexible wiring.
Q4: What measurements can it perform?
A4: It supports radial vibration, thrust position, eccentricity, and differential expansion measurements.
Q5: Is it suitable for harsh environments?
A5: Yes, it is designed for industrial environments with high temperature and strong EMI conditions.
