Product Name: Case Expansion Transducer Systems
Brand Name: Bently Nevada
Model Number: 135613-01
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Commercial Terms
Minimum Order Quantity |
1 Piece |
Price |
Contact for Winnie |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
The Bently Nevada 135613-01 Case Expansion Transducer System is an industrial measurement device designed for monitoring thermal growth and axial expansion of machine casings in rotating equipment. It is part of Bently Nevada’s condition monitoring instrumentation portfolio and operates as a non-contact or displacement-based sensing system depending on configuration.
The system is engineered for harsh industrial environments and features a robust design capable of withstanding high shock and vibration levels. It operates on a +24 Vdc supply (unregulated, 13.5–26 Vdc range) and provides a +1 to +6 Vdc output signal, making it suitable for integration into machinery protection and monitoring systems.
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 135613-01 Case ExpansionTransducer Systems |
| Manufacturer | Bently Nevada |
| Product Type | Case ExpansionTransducer Systems |
| Part Number | 135613-01 |
| Weight | 1.74kg |
| Estimated shipping dimensions | 26.2x11.8x9cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| OperatingTemperature | -25 °C to +85 °C(-13 °F to +185 °F) |
| StorageTemperature | -55 °C to +125 °C(-67 °F to +257 °F) |
| Shock | 250 g for 11 ms |
| Vibration | 10 g @ 0 to 2 kHz |
| Input Power | +24 Vdc, 30 mA minimum |
| Input Power | +13.5 to +26 Vdcunregulated |
| Voltage | +1 to +6 Vdc, all models |
| Output Noise | <10 mV |
The Bently Nevada 135613-01 Case Expansion Transducer Systems operates with a low-power design (minimum 30 mA at +24 Vdc) while maintaining stable measurement accuracy under wide environmental conditions. Its voltage output range of +1 to +6 Vdc provides a linear and easily interpretable signal for control and monitoring systems.
It delivers strong environmental resilience, functioning reliably under high vibration (10 g at 0–2 kHz) and severe shock conditions up to 250 g for 11 ms, ensuring performance stability in demanding industrial settings. The system maintains low output noise (<10 mV), improving signal clarity and measurement precision for long-term monitoring. Its ability to operate across a broad temperature range, from -25°C to +85°C, ensures consistent efficiency in both normal and extreme operating environments, supporting reliable machinery protection and condition monitoring performance.
