Bently Nevada 136719-01 3500/04 Internal Barriers Earthing I/O Module Ready For Ship, China Bently Nevada 136719-01 3500/04 Internal Barriers Earthing I/O Module Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	136719-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Model	136719-01
System	Bently Nevada 3500 Internal Barrier Module
Function	Intrinsically safe signal isolation
Mounting	3500 rack internal slot
Input Compatibility	Proximity, velocity, process transducers
Bandwidth	Up to 30 kHz
Operating Temperature	-20°C to +65°C
Storage Temperature	-40°C to +85°C
Dimension (I/O Module)	241.3 × 24.4 × 163.1 mm
Dimension (Earthing Module)	2.4x11x24cm
Weight (I/O Module)	0.46 kg
Weight (Earthing Module)	0.4kg
Safety Standard	ATEX / IECEx / cNRTLus compliant

Description

The136719-01 Internal Barrier Moduleis designed for the Bently Nevada 3500 machinery protection platform, providing intrinsic safety isolation for transducer systems operating in hazardous environments. It enables direct integration of proximity, velocity, and process monitoring signals into the3500 series rack system, ensuring safe and reliable operation in explosive-rated areas.

Unlike external barrier solutions, the136719-01is fully embedded within the 3500 architecture, maintaining signal integrity while reducing installation complexity and overall system cost. It supports seamless combination with standard and barrier I/O modules within the same rack configuration.

Engineered for industrial safety compliance, this module ensures stable performance in critical monitoring applications across energy, oil & gas, and heavy industry sectors, while meeting international hazardous area certification standards.

Applications

Power plants: Used for generator set vibration monitoring and relay protection.
Substations: Supports bus differential protection, line monitoring, and signal acquisition.
Chemical plants: Enables intrinsically safe automation and process control integration.
Steel mills: Ensures reliable operation under high temperature and electromagnetic interference.
Machinery manufacturing: Applied in automated production lines, robotics, and packaging systems.

Features

Fully integrated internal barrier design for 3500 rack
Intrinsically safe signal isolation for hazardous zones
Compatible with multiple Bently Nevada transducer systems
Supports mixed standard and barrier I/O modules
High reliability in industrial safety environments

Functions

Provides explosion protection for connected sensors
Ensures safe signal transmission within hazardous areas
Maintains system performance without external barrier units
Enables safe rack-level integration of monitoring modules
Supports condition monitoring and protection logic systems

FAQ

Q1: What is the 136719-01 used for?
A1: It provides intrinsic safety barrier protection for transducers in the Bently Nevada 3500 monitoring system.

Q2: Can standard and barrier modules be used together?
A2: Yes, both standard and internal barrier I/O modules can operate within the same 3500 rack.

Q3: What types of sensors are supported?
A3: It supports proximity probes, velocity sensors, and process variable monitoring devices.

Q4: Is external wiring required for this barrier?
A4: No, the barrier is fully integrated into the 3500 system backplane design.

Q5: What industries commonly use this module?
A5: It is widely used in power generation, petrochemical, steel manufacturing, and machinery automation industries.

Spares

Number	Describe
136719-01	Earthing I/O Module for 3500 internal barrier system grounding connection
138257-01	Earthing Module Front Panel for 3500 system internal barrier configuration
135473-01	3500/25 I/O Module with Internal Barriers and internal terminations
135489-01	3500/42, /70, /72 I/O Module with Internal Barriers (4 prox/accel channels) and internal terminations
135489-02	3500/42, /70 I/O Module with Internal Barriers (2 prox/accel + 2 Velomitor channels) and internal terminations
135489-03	3500/42, /70 I/O Module with Internal Barriers (4 Velomitor channels) and internal terminations
135489-04	3500/40 I/O Module with Internal Barriers and internal terminations
136703-01	3500/50 I/O Module with Internal Barriers and internal terminations
136711-01	3500/60 I/O Module with Internal Barriers and internal terminations
136711-02	3500/61 I/O Module with Internal Barriers and internal terminations
137110-01	3500/62 I/O Module with Internal Barriers and internal terminations
