Product Name:3300 Ceramic Capped Proximity Probes
Brand Name:Bently Nevada
Model Number:146054-010-20-02-05
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
146054-010-20-02-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Specification Area | Details |
|---|---|
| Measurement Function: | Provides non-contact vibration and shaft position detection, enabling continuous machine condition monitoring in rotating equipment systems, |
| Probe Type: | Ceramic capped 8 mm proximity probe with high corrosion resistance and enhanced durability, |
| Thread Standard: | 3/8-24 UNF threaded design, ensuring stable mechanical mounting and secure alignment in industrial housings, |
| Cable System: | Compatible with 3300 XL extension cable system, supporting stable long-distance signal transmission with low attenuation, |
| Pressure Rating: | Rated for up to 34 bar (500 psi) sealing performance, suitable for chemical and process industries, |
| Dimension: | Case length configurable from 0.8 to 4.0 in, total cable length options up to 9.0 meters depending on system configuration, |
| Weight: | Approx. 0.3–0.7 kg depending on cable and armor selection, optimized for stable industrial installation, |
| Industrial Function: | Used for vibration monitoring, axial displacement detection, and predictive maintenance of rotating machinery systems, |
The 146054-010-20-02-05 ceramic capped proximity probe is engineered for demanding industrial environments requiring high resistance to corrosion, pressure, and aggressive chemicals. Built on the Bently Nevada 3300 platform, including compatibility with 146054 and modified armored configurations, it ensures stable non-contact measurement performance in harsh operating conditions.
Designed with an alumina ceramic sensing cap and stainless-steel probe housing, the system delivers reliable vibration and position monitoring for rotating machinery. When paired with a 3300 Proximitor Sensor and extension cable, it provides accurate eddy-current signal output for predictive maintenance and machine protection.
The 146054-010-20-02-05 supports long-term installation stability, making it suitable for chemical processing, petrochemical units, and high-pressure monitoring systems where durability and measurement precision are critical.
Designed for extreme industrial environments with operating temperature range up to +177°C, pressure resistance up to 34 bar, and corrosion-resistant ceramic construction. Certified compliance includes RoHS, FCC Part 15, ATEX/IECEx hazardous area approvals, and maritime classification standards. Suitable for Zone 0/1/2 installations depending on configuration, ensuring safe deployment in oil, gas, and chemical processing facilities. High sealing reliability and environmental protection make it suitable for long-term operation in aggressive and high-risk industrial conditions.
Q1: What is the main use of 146054 ceramic capped probe?
A1: It is used for non-contact vibration and position monitoring in rotating machinery systems.
Q2: Can 146054-010-20-02-05 work in corrosive environments?
A2: Yes, the ceramic cap and stainless steel body provide strong resistance to aggressive chemicals.
Q3: Is it compatible with 3300 XL systems?
A3: Yes, it fully integrates with 3300 XL Proximitor Sensor and extension cable systems.
Q4: What pressure can this probe withstand?
A4: It is rated for up to 34 bar (500 psi) sealing performance.
Q5: Where is this probe commonly used?
A5: It is widely used in power plants, chemical plants, and heavy industrial machinery systems.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
