Product Name:low-level analog input module
Brand Name:Honeywell
Model Number:8C-PAIMA1 51454473-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-PAIMA1 51454473-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
8C-PAIMA1 51454473-175 |
|
System Type |
Series 8 Low Level Analog Input |
|
Input Type |
RTD & Thermocouple |
|
Channels |
16 isolated channels |
|
Voltage Rating |
24 VDC |
|
Scan Rate |
1 second fixed |
|
Resolution |
High-precision digital conversion |
|
IOTA Compatibility |
8C-TAIMA1 (Coated / Non-redundant) |
|
Mounting Type |
DIN rail system integration |
|
Communication |
Experion PKS / PlantCruise compatible |
|
Operating Temperature |
-20°C to +60°C |
|
Storage Temperature |
-40°C to +85°C |
|
Humidity |
5–95% non-condensing |
|
Dimensions |
6x15x14.3cm |
|
Weight |
0.38kg |
|
Protection |
Conformal coated industrial design |
The 8C-PAIMA1 51454473-175 is a Series 8 low-level analog input module engineered for precise acquisition of RTD and thermocouple signals in industrial control environments. It converts temperature-based field measurements into stable digital data for Honeywell Experion-based systems, supporting accurate process monitoring across demanding applications.
Designed within the Series 8 I/O architecture, the 8C-PAIMA1 provides 16 fully isolated input channels with high signal integrity and reliable cold junction compensation. It ensures consistent temperature data capture even under electrical noise, vibration, or harsh environmental conditions.
With built-in open sensor detection, 1-second scanning, and advanced filtering, 8C-PAIMA1 enhances operational safety and process stability. It integrates seamlessly with TAIMA1 IOTA platforms, making it suitable for redundant and non-redundant configurations in modern distributed control systems.
Q1: What is the main function of 8C-PAIMA1?
A1: It collects and converts RTD and thermocouple signals into digital data for industrial control systems.
Q2: How many input channels does 8C-PAIMA1 support?
A2: It supports 16 fully isolated temperature input channels.
Q3: Is 8C-PAIMA1 compatible with Honeywell Experion systems?
A3: Yes, it is designed for seamless integration with Experion and Series 8 architecture.
Q4: Does the module support open sensor detection?
A4: Yes, it includes built-in open thermocouple detection for fault protection.
Q5: Can 8C-PAIMA1 be used in harsh environments?
A5: Yes, its conformal-coated design ensures reliable operation in demanding industrial conditions.
| Number (I/O Module - Coated) | Description |
|---|---|
| 8C-PAIH54 | High-level AI HART, Differential, 16 channels |
| 8C-TAIDA1 | AI IOTA, 9-inch standard analog input termination assembly |
| 8C-TAIDB1 | AI IOTA, redundant configuration, 12-inch |
| 8C-PAIHA1 | High-level AI HART, Single-ended, 16 channels |
| 8C-PAINA1 | High-level AI without HART, Single-ended, 16 channels |
| 8C-TAIXA1 | AI IOTA, standard 6-inch module termination |
| 8C-TAIXB1 | AI IOTA, redundant 12-inch configuration |
| 8C-PAIMA1 | Low-level AI for RTD & TC temperature input, 16 channels |
| 8C-TAIMA1 | Low-level AI IOTA, 9-inch temperature input termination |
| 8C-PAOHA1 | Analog Output module with HART, 16 channels |
| 8C-PAONA1 | Analog Output module without HART, 16 channels |
| 8C-TAOXA1 | AO IOTA, standard 6-inch termination assembly |
| 8C-TAOXB1 | AO IOTA, redundant 12-inch configuration |
| 8C-PDILA1 | Digital Input module, 24V DC, 32 channels |
| 8C-PDISA1 | Digital Input Sequence of Events module, 32 channels |
| 8C-PDIPA1 | Digital Input Pulse Accumulation module, 24V DC, 32 channels |
| 8C-TDILA1 | DI IOTA, 24V digital input termination assembly, 9-inch |
| 8C-TDILB1 | DI IOTA, redundant 12-inch digital input termination |
