Product Name:Buffered Signal Output Module
Brand Name:Bently Nevada
Model Number:147364-01
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
147364-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 147364-01 Buffered Signal Output Module |
| Series | Bently Nevada 3500 System |
| Function | Buffered signal output for monitoring system |
| System Compatibility | 3500/40M, 3500/42M, M-series monitors |
| Signal Type | Conditioned vibration & process signals |
| Interface Role | External diagnostic data access |
| Communication | Rack-based signal buffering |
| Dimensions | 241.3 mm × 24.4 mm × 241.8 mm |
| Weight | 0.91 kg (module dependent configuration) |
| Installation Slot | 3500 rack full-height front slot |
| Operating Temperature | -30°C to +65°C |
The 147364-01 3500 Buffered Signal Output Module is designed for the Bently Nevada 3500 monitoring platform, enabling reliable access to conditioned machine signals for advanced analysis and system integration. It provides buffered outputs that allow external diagnostic equipment to receive accurate real-time vibration and process data without disturbing the primary monitoring loop.
In a standard 3500 rack configuration, 147364-01 supports seamless signal distribution from M-series monitors to external systems such as condition monitoring software and engineering tools. It is commonly used in conjunction with modules like the 3500/40M and 3500/42M to extend diagnostic capability across industrial assets.
This module plays a key role in machinery health monitoring architectures by ensuring stable signal replication for external analysis platforms. It is suitable for both steady-state and dynamic data applications, improving system visibility, troubleshooting efficiency, and predictive maintenance performance.
Q1: What is the main function of 147364-01?
A1: It provides buffered signal outputs for external monitoring and diagnostic systems.
Q2: Which system is 147364-01 used with?
A2: It is designed for the Bently Nevada 3500 monitoring system.
Q3: Does it affect the primary monitoring loop?
A3: No, it operates independently without impacting core monitoring functions.
Q4: What type of data does it output?
A4: It outputs conditioned vibration and process signals for analysis.
Q5: Where is this module commonly installed?
A5: It is installed in industrial racks for power plants, refineries, and machinery monitoring systems.
| Number | I/O Module (Coated) / Description |
|---|---|
| 288055-01 | Standard Transient Data Interface Module with USB cable for data acquisition and system communication |
| 100M2833 | 10 foot A to B USB cable for TDI module connectivity and data transfer |
| 146031-01 | 10Base-T/100Base-TX Ethernet I/O module for network-based industrial communication |
| 146031-02 | 100Base-FX fiber optic I/O module designed for high-speed and noise-immune data transmission |
| 147364-01 | 3500 Buffered Signal Output module providing conditioned signal outputs for monitoring systems |
| 161580-01 | 3500/22M TDI Operation and Maintenance Manual for installation, configuration, and troubleshooting guidance |
| 164466-01 | Network accessories datasheet providing technical reference for system integration components |
| 00580441 | Internal termination connector header, 3-position, green, used for I/O module wiring termination |
| 00580436 | Internal termination connector header, 6-position, green, designed for multi-channel I/O module connections |
