Product Name:Advanced Vibration Monitoring System
Brand Name:Bently Nevada
Model Number:1900/55
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
1900/55 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 1900/55 |
| Input Type | Vibration, speed, temperature |
| Communication | Modbus (optional depending configuration) |
| Power Supply | 110/220 Vac to 24 Vdc external supply |
| Mounting Type | DIN rail / bulkhead / enclosure |
| Operating Temp | -20°C to +70°C |
| Storage Temp | -30°C to +90°C |
| Dimension | 196.9 mm × 149.4 mm × 74.4 mm |
| Weight | ~0.77 kg (module typical) |
| Housing Option | NEMA 4X / IP66 enclosure |
The 1900/55 General Purpose Equipment Monitor is engineered for continuous condition monitoring and protection of industrial machinery across a wide range of applications. Designed for flexible system integration, it delivers reliable multi-channel measurement for vibration, speed, and temperature signals in real-time.
The 1900/55 platform supports compatibility with multiple Bently Nevada systems, including 1900/65A and related monitoring architectures, enabling scalable deployment in modern automation environments. Its modular design allows operators to configure inputs, outputs, and alarm logic according to plant requirements.
With built-in communication capabilities and configurable software, the 1900/55 provides efficient data acquisition, alarm processing, and system diagnostics. It is widely used in power generation, petrochemical processing, and heavy industry where stable and accurate equipment protection is essential.
Q1: What is the main purpose of the 1900/55?
A1: It is used for continuous monitoring and protection of industrial rotating equipment.
Q2: Which sensors are compatible with the 1900/55?
A2: It supports vibration, speed, and temperature sensors including proximity and RTD types.
Q3: Can the 1900/55 be integrated into PLC systems?
A3: Yes, it supports Modbus communication for PLC and SCADA integration.
Q4: Is the 1900/55 suitable for harsh environments?
A4: Yes, it is designed for industrial conditions including high temperature and EMI areas.
Q5: Does it support remote configuration?
A5: Yes, configuration can be managed via software through network connection.
| Number (I/O Module (Coated)) | Description |
|---|---|
| 167699-02 | 1900/65A Display Module |
| 173400 | 1900/65A User Guide |
| 172250 | 1900/65 Modbus Gateway User's Guide |
| 173089 | 1900/65A Field Wiring Diagrams |
| 02200794 | Power supply, 110/220 Vac to 24 Vdc, 2.5 A, DIN rail mount |
| 02200121 | DIN rail end bracket |
| 168374 | 35 mm DIN rail mounting clip for 1900/65A Monitor Module |
| 168495 | Bulkhead mounting plate |
| 168547-0010-01-01 | 3 m (10 ft) PVC cable, assembled |
| 168547-0010-01-02 | 3 m (10 ft) PVC cable, unassembled |
| 168547-0010-02-01 | 3 m (10 ft) TEF cable, assembled |
| 168547-0010-02-02 | 3 m (10 ft) TEF cable, unassembled |
| 168628 | Stainless steel NEMA 4X weatherproof door for panel-mount display assembly |
| 168629 | Painted steel NEMA 4 weatherproof door for panel-mount display assembly |
| 168944 | Fiberglass NEMA 4X/IP66 weatherproof housing with window in door |
| 284785 | MTL 7728(-) barrier |
| 175502 | MTL 7796(-) barrier |
| 172555 | Modbus/TCP (Ethernet) to Modbus/RTU (Serial) Converter |
| 169825-01 | Training CD |
