Product Name:Proximity Probe Housing Assemblies
Brand Name:Bently Nevada
Model Number:21000-16-10-15-102-03-02
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
21000-16-10-15-102-03-02 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Product Model |
21000-16-10-15-102-03-02 |
|
Housing Type |
21000 Aluminum Probe Housing Assembly |
|
Compatible Probe |
3300 XL 8 mm Reverse Mount Probe |
|
Probe Cable Length |
1.0 m (39 in) |
|
Standoff Adapter Length |
1.5 in (38 mm) |
|
Probe Penetration Length |
10.2 in (259 mm) |
|
Fitting Option |
3/4-14 NPT plug + reducer + cable seal grip |
|
Mounting Thread |
3/4-14 NPT |
|
Housing Material |
Aluminum body with 304 stainless steel sleeve |
|
Operating Temperature |
-51°C to +177°C |
|
Hazardous Area Rating |
CSA Explosion-Proof Certified |
|
Protection Standard |
CSA Type 4 Enclosure |
|
Approximate Weight |
1.38kg |
|
Typical Dimension |
Long sleeve external mounting structure |
|
Compliance |
API 670 / RoHS |
|
Dimension |
49x8.5x8.5cm |
Bently Nevada 21000-16-10-15-102-03-02 proximity probe housing assembly is engineered for reliable external mounting of vibration and position monitoring probes in demanding industrial environments. Built with a rugged aluminum housing and stainless-steel sleeve, this configuration supports the 3300 XL 8 mm reverse mount probe series while maintaining excellent mechanical stability and environmental protection for rotating equipment applications.
Designed for turbine systems, compressors, pumps, and heavy-duty process machinery, 21000-16-10-15-102-03-02 offers a 1.0 m probe cable, 1.5 in standoff adapter, and extended probe penetration structure for installations requiring deeper machine access. The assembly supports hazardous-area applications and complies with API 670 monitoring requirements widely used across power generation and petrochemical industries.
Compared with conventional mounting structures, 21000, 24701, and 164818 housing assemblies improve probe alignment accuracy, simplify conduit routing, and enhance long-term signal reliability. The modular construction also allows flexible integration with Bently Nevada proximity transducer systems for continuous machinery protection and predictive maintenance programs.
Q1: What is the primary use of the 21000-16-10-15-102-03-02 housing assembly?
A1: It is mainly used for external mounting and protection of Bently Nevada proximity probes in rotating machinery monitoring systems.
Q2: Which probe series is compatible with this housing assembly?
A2: This model is configured for the 3300 XL 8 mm reverse mount proximity probe.
Q3: Is the 21000-16-10-15-102-03-02 suitable for hazardous environments?
A3: Yes, it supports CSA-certified explosion-proof applications for hazardous industrial areas.
Q4: What industries commonly use this product?
A4: It is widely used in power generation, petrochemical processing, oil & gas, steel production, and industrial manufacturing facilities.
Q5: What material is used for the housing structure?
A5: The assembly uses an aluminum housing body combined with a 304 stainless-steel probe sleeve for durability and corrosion resistance.
|
Number |
Describe |
|
37948-01 |
Probe Support / Oil Seal, recommended for sleeves longer than 305 mm (12 in) |
|
44382-AAA |
Individual Probe Sleeve for 21000/24701 Proximity Probe Housings |
|
21003-AAA |
Individual Standoff Adapter for proximity probe housing assemblies |
|
330105-02-12-05-00-00 |
Spare 3300 XL 8 mm Reverse Mount Probe, 0.5 m length, without connector |
|
330105-02-12-10-02-05 |
Spare 3300 XL 8 mm Reverse Mount Probe, 1.0 m length, with miniature ClickLoc connector and multiple approvals |
|
330105-02-12-50-02-05 |
Spare 3300 XL 8 mm Reverse Mount Probe, 5.0 m length, with miniature ClickLoc connector |
|
330105-02-12-90-02-05 |
Spare 3300 XL 8 mm Reverse Mount Probe, 9.0 m length, with approvals |
|
330906-02-12-05-00-00 |
Spare 3300 NSv Reverse Mount Probe, 0.5 m length, without connector |
|
330906-02-12-10-02-05 |
Spare 3300 NSv Reverse Mount Probe, 1.0 m length, with miniature ClickLoc connector |
|
330906-02-12-50-02-05 |
Spare 3300 NSv Reverse Mount Probe, 5.0 m length, with multiple approvals |
|
330906-02-12-70-02-05 |
Spare 3300 NSv Reverse Mount Probe, 7.0 m length, with miniature ClickLoc connector |
|
330705-02-18-10-00-00 |
Spare 3300 XL 11 mm Reverse Mount Probe, 0.5 m length, without connector |
|
330705-02-18-10-02-05 |
Spare 3300 XL 11 mm Reverse Mount Probe, 0.5 m length, with miniature male coaxial connector |
|
330705-02-18-50-02-05 |
Spare 3300 XL 11 mm Reverse Mount Probe, 5.0 m length, with approvals |
|
330705-02-18-90-02-05 |
Spare 3300 XL 11 mm Reverse Mount Probe, 9.0 m length, with miniature male coaxial connector |
