Product Name:extension cable
Brand Name:Bently Nevada
Model Number:21747-075-01
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
21747-075-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 21747-075-01, extension cable for Bently Nevada 7200 proximity transducer system signal transmission |
| System Compatibility | 7200 5 mm and 8 mm probe systems, Proximitor integration with stable signal continuity |
| Cable Type | Shielded coaxial industrial cable, optimized for low-noise vibration signal transfer |
| Signal Transmission | High-integrity analog signal transmission between probe and monitoring module |
| Electrical Length | Matched system configuration length, optimized for 5 m and 9 m setups |
| Operating Temperature | -34°C to +177°C, suitable for harsh industrial environments |
| Dimension | Approx. industrial standard cable length configuration, flexible routing design |
| Weight | Lightweight construction, optimized for panel and field installation use |
The 21747-075-01 extension cable is designed as a critical interconnect component for Bently Nevada 7200 proximity transducer systems, ensuring stable and low-noise signal transmission between the probe assembly and Proximitor unit. It supports high-precision vibration and displacement monitoring in industrial rotating machinery.
Engineered for compatibility with both 5 mm and 8 mm probe configurations, the 21747-075-01 provides reliable performance in demanding environments where signal integrity is essential. It is commonly paired with 18745 series Proximitors and 7200 probe systems to form a complete measurement chain.
Built for durability and long service life, the 21747-075-01 ensures consistent electrical performance under mechanical stress, temperature variation, and industrial vibration, making it suitable for predictive maintenance and continuous condition monitoring applications.
Power plants: Used for turbine and generator vibration signal transmission and condition monitoring systems.
Substations: Supports relay protection systems and real-time equipment signal communication.
Chemical plants: Enables stable monitoring in corrosive and hazardous process environments.
Steel mills: Ensures reliable signal transfer in high-temperature and electromagnetic interference zones.
Machinery manufacturing plants: Applied in automated production lines, CNC equipment, and robotics control systems.
Q1: What is the function of the 21747-075-01 cable?
A1: It transmits proximity probe signals to the Proximitor with stable, low-noise performance.
Q2: Which systems is the 21747-075-01 compatible with?
A2: It is designed for Bently Nevada 7200 5 mm and 8 mm transducer systems.
Q3: Can it be used in harsh environments?
A3: Yes, it is built for high temperature, vibration, and industrial EMI conditions.
Q4: Does it affect signal accuracy?
A4: No, its shielded design maintains high signal integrity and measurement accuracy.
Q5: What equipment commonly uses this cable?
A5: It is used in turbines, compressors, pumps, motors, and generators monitoring systems.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
