Brand: Bently Nevada
Series: 24701
Model: 24701-00-00-15-037-04-02
Official description: Stainless Steel Proximity Probe Housing Assembly
Official source: Baker Hughes Bently Nevada datasheet 141600 Rev. AC.
Configuration note: Configuration includes no probe and no probe cable; confirm the required compatible probe system before quotation.
Provides a protected external mounting arrangement for a compatible reverse-mount proximity probe on machinery. The housing supports mechanical positioning, conduit entry and service access; the measuring function depends on the separately selected probe, cable and Proximitor system.
|
Housing material
|
303 stainless steel body with 304 stainless steel sleeve
|
|
Typical mass
|
1.8 kg (4.1 lb), without fittings
|
|
Probe option 00
|
Probe not required / not supplied by this ordering option
|
|
Probe cable option 00
|
Probe cable not required / not supplied
|
|
Standoff option 15
|
1.5 in (38 mm)
|
|
Probe penetration option 037
|
3.7 in (94 mm)
|
|
Fitting option 04
|
One 3/4-14 NPT plug only
|
|
Mounting thread option 02
|
3/4-14 NPT
|
The assembly uses an all-metal stainless-steel body, screw-on dome cover, threaded conduit ports, probe sleeve, O-rings and thread sealing provisions. This exact configuration has no probe or probe cable. Its 3/4-14 NPT mounting thread is required with the non-zero standoff option.
|
Housing type
|
24701 stainless steel proximity probe housing
|
|
RoHS
|
RoHS Directive 2011/65/EU is listed in the official datasheet
|
|
Hazardous-area status
|
Do not treat standard 24701 as a CA24701 explosion-proof housing; confirm the exact approval requirement and installation method
|
|
Probe temperature limit
|
Depends on the separately selected probe system; confirm before quotation
|
|
Environmental sealing
|
Confirm conduit fittings, plug installation, O-rings and site enclosure requirements
|
Confirm the compatible reverse-mount probe family and approval option. Verify that the 1.5 in standoff and 3.7 in penetration dimensions suit the machine geometry. Install the 3/4-14 NPT mounting thread and supplied plug per the official instructions. Provide sleeve support if a future C plus D dimension exceeds 300 mm. Check clearance, probe gap and conduit sealing before commissioning.
|
Physical stock
|
Confirm before quotation
|
|
Condition: New, Used or Refurbished
|
Subject to verification for the quoted unit
|
|
Current product and nameplate photos
|
Available on request
|
|
Warranty period
|
Available on request and confirmed in the quotation
|
|
Dispatch time
|
Confirm before quotation
|
|
Testing status and scope
|
Subject to verification; available records can be requested
|
|
Payment methods
|
Available on request and stated on the proforma invoice
|
|
Quotation response time
|
Available on request
|
|
Transaction confidence
|
Itemized quotation, company details, invoice, pre-shipment verification and shipment records are provided as applicable
|
Is this actual stock?
Confirm before quotation for the requested quantity.
Is the unit new, used or refurbished?
Subject to verification for the specific unit offered.
Can current product and nameplate photos be provided?
Available on request before order confirmation.
What is the warranty?
Available on request and confirmed in the written quotation.
When can it ship?
Confirm before quotation after quantity and destination are known.
Has it been tested?
Subject to verification. Request the applicable test scope and available records.
Which payment methods are supported?
Available on request and listed on the proforma invoice.
How is the transaction verified?
Request an itemized quotation, company and banking details, current-unit verification, invoice and shipment documentation.
|
