Product Name: 8mm Eddy Current Sensor
Brand Name: Emerson
Model Number: PR6423/10R-141 CON031
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Commercial Terms
Minimum Order Quantity |
1 Piece |
Price |
Contact for Winnie |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Emerson PR6423/10R-141 CON031 8mm Eddy Current Sensor |
| Manufacturer | Emerson |
| Product Type | 8mm Eddy Current Sensor |
| Part Number | PR6423/10R-141 CON031 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 15x2.7x18.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Tip Diameter | 8mm |
| Case Thread | Reverse Mount |
| Adapter Plug | Without |
| Cable Length | 10.0m |
| Cable End | Open |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | ISO: 8 V/mm (203.2 mV/mil) ± 5% @ temperature range 0 to 45°C (+32 to +113°F) |
| Deviation from best fit straight line (DSL) | ± 0.025 mm (± 1 mil) @ temperature range 0 to 45°C (+32 to +113°F) |
| Minimum Shaft Diameter | 25 mm (0.79”) |
| Operating Temperature Range | Sensor incl. 1m Cable: -35 to +180°C (-31 to 356°F); Cable & Connector: -35 to +150°C (-31 to 302°F) |
| Material | Sensor Tip (PEEK Polyether Ether Ketone), Case (Stainless Steel); Cable (PTFE Polytetrafluoroethylene), Connector (Brass, nickel-plated) |
The Emerson PR6423/10R-141 CON031 is an 8mm eddy current non-contact displacement sensor designed for high-precision monitoring of shaft position, vibration, and dynamic movement in turbomachinery applications. It is widely used in critical rotating equipment where real-time condition monitoring is essential for safe and efficient operation.
Engineered for harsh industrial environments, the PR6423/10R-141 CON031 provides reliable measurement performance for steam turbines, gas turbines, compressors, pumps, fans, and gearboxes. Its non-contact measurement principle ensures long-term stability even under high-speed and high-temperature operating conditions.
With a robust stainless steel housing, PEEK sensor tip, and PTFE cable, the sensor is designed for durability and long service life in demanding industrial systems.
Non-Contact Shaft Displacement Measurement: Measures radial and axial shaft displacement without physical contact, ensuring accurate and stable monitoring of rotating equipment.
Vibration and Eccentricity Detection: Detects vibration patterns and shaft eccentricity in real time to support early fault identification in turbomachinery.
Dynamic Position Monitoring: Provides continuous tracking of shaft position changes in high-speed rotating machinery.
Condition Monitoring Support: Delivers critical data for predictive maintenance and equipment health monitoring systems.
Signal Conversion for Control Systems: Converts mechanical movement into proportional electrical signals for industrial monitoring and protection systems.
High-Temperature Industrial Operation: Maintains accurate performance under extreme temperature conditions in harsh operating environments.
Turbomachinery Protection Integration: Supports integration with turbine and compressor protection systems for safe operation and shutdown control.
The PR6423/10R-141 CON031 provides continuous real-time monitoring of shaft displacement, vibration, and dynamic behavior in rotating machinery. It enables precise detection of mechanical deviations such as imbalance, misalignment, and eccentricity, which are critical indicators of equipment health.
The sensor delivers stable analog output signals that are processed by condition monitoring and protection systems to ensure safe operation of turbines, compressors, pumps, and other rotating equipment. Its non-contact measurement technology ensures reliable operation even under high-speed rotation and harsh environmental conditions.
With strong thermal and mechanical resistance, the PR6423/10R-141 CON031 maintains accurate signal output across wide temperature ranges and demanding industrial conditions. This supports predictive maintenance strategies and helps reduce unplanned downtime by enabling early fault detection and system protection.
Q1: What is the Emerson PR6423/10R-141 CON031 8mm Eddy Current Sensor used for?
A1: The PR6423/10R-141 CON031 is used for non-contact measurement of shaft displacement, vibration, and position in turbomachinery and rotating industrial equipment.
Q2: How does the Emerson PR6423/10R-141 CON031 8mm Eddy Current Sensor measure displacement?
A2: The PR6423/10R-141 CON031 uses eddy current technology to convert changes in shaft position into proportional electrical signals without physical contact.
Q3: What is the measurement range of the Emerson PR6423/10R-141 CON031 8mm Eddy Current Sensor?
A3: The PR6423/10R-141 CON031 provides a linear measurement range of 2 mm with an initial air gap of 0.5 mm.
Q4: What machines typically use the Emerson PR6423/10R-141 CON031 8mm Eddy Current Sensor?
A4: The PR6423/10R-141 CON031 is commonly used in steam turbines, gas turbines, compressors, pumps, fans, and gearboxes.
Q5: What is the operating temperature range of the Emerson PR6423/10R-141 CON031 8mm Eddy Current Sensor?
A5: The PR6423/10R-141 CON031 operates from -35°C to +180°C for the sensor and up to +150°C for the cable and connector.
