Brand: Bently Nevada
Series: 3300 XL NSv
Model: 330901-00-55-05-02-05
Official description: 3300 NSv Probe, 1/4-28 UNF Thread, Without Armor
Official source: Baker Hughes Bently Nevada datasheet 147385 Rev. R.
Configuration note: Use only with a compatible 3300 XL NSv system; confirm approval documents and installation drawing before quotation.
Designed for non-contacting vibration and position measurement where small targets or restricted side-view clearance make the 3300 XL NSv system appropriate. The complete system can support radial vibration, axial position, Keyphasor and speed measurements when correctly configured.
|
Probe type
|
3300 NSv standard-mount probe, 1/4-28 UNF thread, without armor
|
|
Unthreaded length option 00
|
0.0 in
|
|
Overall case length option 55
|
5.5 in
|
|
Total length option 05
|
0.5 m (20 in)
|
|
Connector option 02
|
Miniature coaxial ClickLoc connector, standard cable
|
|
Approval option 05
|
Multiple approvals
|
|
System linear range
|
1.5 mm (60 mils), approximately 0.25 to 1.75 mm from target
|
|
System scale factor
|
7.87 V/mm (200 mV/mil), +12.5%/-20% including interchangeability error
|
|
Recommended gap
|
1.0 mm (40 mils)
|
|
System frequency response
|
0 to 10 kHz, +0/-3 dB typical
|
The unarmored probe uses a 1/4-28 UNF standard-mount case, AISI 304 stainless-steel case, PPS tip and 75 ohm FEP-insulated coaxial cable. Option 02 provides a miniature coaxial ClickLoc connector without a connector protector.
|
Probe operating and storage
|
-52°C to +177°C (-62°F to +351°F)
|
|
Pressure-seal caution
|
Sustained exposure below -34°C (-30°F) may cause premature pressure-seal failure
|
|
Relative humidity
|
100% condensing, non-submersible when connectors are protected
|
|
Approval option
|
05 indicates multiple approvals; verify certificates and required installation drawings
|
|
Installation protection
|
Approved systems may require Proximitor terminals to be installed with at least IP54 protection
|
Match this 0.5 m NSv probe with only compatible 3300 XL NSv extension cable and Proximitor components. Do not mix it with 3000-series or 7000-series parts. Confirm 1/4-28 UNF thread engagement, target size, probe spacing and counterbore clearance. Use the published 1.0 mm gap only after the complete system is verified.
|
Physical stock
|
Confirm before quotation
|
|
Condition: New, Used or Refurbished
|
Subject to verification for the quoted unit
|
|
Current product and nameplate photos
|
Available on request
|
|
Warranty period
|
Available on request and confirmed in the quotation
|
|
Dispatch time
|
Confirm before quotation
|
|
Testing status and scope
|
Subject to verification; available records can be requested
|
|
Payment methods
|
Available on request and stated on the proforma invoice
|
|
Quotation response time
|
Available on request
|
|
Transaction confidence
|
Itemized quotation, company details, invoice, pre-shipment verification and shipment records are provided as applicable
|
Is this actual stock?
Confirm before quotation for the requested quantity.
Is the unit new, used or refurbished?
Subject to verification for the specific unit offered.
Can current product and nameplate photos be provided?
Available on request before order confirmation.
What is the warranty?
Available on request and confirmed in the written quotation.
When can it ship?
Confirm before quotation after quantity and destination are known.
Has it been tested?
Subject to verification. Request the applicable test scope and available records.
Which payment methods are supported?
Available on request and listed on the proforma invoice.
How is the transaction verified?
Request an itemized quotation, company and banking details, current-unit verification, invoice and shipment documentation.
|
