Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330101-00-70-10-02-CN
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-00-70-10-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 330101-00-70-10-02-CN |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Probe Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Total Cable Length | 1.0 m (3.3 ft) |
| Cable Type | Standard Cable |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Measurement Principle | Eddy Current Proximity Sensing |
| Linear Range | 2 mm (80 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Minimum Target Size | 15.2 mm Diameter |
| Recommended Shaft Diameter | ≥76.2 mm (3 in) |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Operating Temperature | -52°C to +177°C |
| Tensile Strength | 330 N (75 lbf) |
| Minimum Bend Radius | 25.4 mm |
| Approximate Probe Weight | 323 g/m |
| Typical System Weight | 0.7 kg |
| Dimension | 8 mm probe diameter, 1 m overall cable length |
330101-00-70-10-02-CN is a high-performance proximity probe from the Bently Nevada 3300 XL 8 mm series, engineered for precise non-contact shaft vibration and position monitoring in critical rotating machinery. Designed with a rugged 8 mm probe structure and advanced eddy-current sensing technology, it delivers stable and repeatable measurement results in demanding industrial environments.
As part of the 3300 XL proximity transducer family, 330101-00-70-10-02-CN offers excellent interchangeability with compatible probes, extension cables, and Proximitor sensors. Its robust construction, corrosion-resistant materials, and ClickLoc connector technology simplify installation while enhancing long-term reliability.
This probe is widely used in turbines, compressors, motors, generators, and other fluid-film bearing machines where accurate displacement monitoring is essential. The design supports predictive maintenance programs, machinery protection systems, and condition monitoring solutions, helping facilities improve equipment availability and reduce unplanned downtime.
Power Plants: Turbine shaft vibration monitoring; Generator rotor position measurement; Machinery protection system integration.
Oil & Gas Facilities: Compressor condition monitoring; Gas turbine vibration analysis; Critical rotating equipment protection.
Petrochemical Plants: Pump and motor health monitoring; Process equipment reliability improvement; Predictive maintenance implementation.
Steel Mills: Monitoring heavy-duty rolling machinery; Operation in high-temperature industrial environments; Rotating equipment condition assessment.
Machinery Manufacturing Plants: Automated production equipment monitoring; Dynamic shaft displacement measurement; Industrial machine performance optimization.
Marine & Offshore Platforms: Rotating machinery protection; Generator and propulsion system monitoring; Reliable operation under demanding conditions.
Q1: What is the primary function of the 330101-00-70-10-02-CN?
A1: It provides non-contact measurement of shaft vibration and position in rotating machinery.
Q2: Is the 330101-00-70-10-02-CN suitable for turbine monitoring?
A2: Yes, it is widely used for turbine shaft vibration and rotor position monitoring.
Q3: What sensing technology does this probe use?
A3: It utilizes eddy-current proximity sensing technology for accurate displacement measurement.
Q4: Can this probe be integrated into predictive maintenance systems?
A4: Yes, it supplies reliable condition-monitoring data for predictive maintenance programs.
Q5: What industries commonly use the 330101-00-70-10-02-CN?
A5: Power generation, oil & gas, petrochemical processing, steel production, marine, and manufacturing industries frequently use this probe.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
