Product Name:Analog Input Module
Brand Name:Honeywell
Model Number:8C-PAIHA1 51454470-275
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-PAIHA1 51454470-275 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
8C-PAIHA1 51454470-275 |
|
System Type |
Series 8 High-Level Analog Input |
|
Input Type |
4–20 mA HART (Single-ended) |
|
Channels |
16 channels |
|
Resolution |
16-bit A/D conversion |
|
Scan Rate |
50 ms |
|
Voltage Rating |
24 VDC |
|
Module Current |
110 mA |
|
IOTA Compatibility |
8C-TAIXA1 / 8C-TAIXB1 |
|
Isolation |
1000 VAC / ±1000 VDC |
|
Mounting |
DIN rail cabinet integration |
|
Communication |
HART + Experion PKS |
|
Operating Temp |
-20°C to +60°C |
|
Storage Temp |
-40°C to +85°C |
|
Humidity |
5–95% non-condensing |
|
Dimensions |
6x15.6x14.3cm |
|
Weight |
0.3kg |
|
Protection |
Conformal coated industrial design |
The 8C-PAIHA1 51454470-275 is a Series 8 high-level analog input module designed for single-ended HART-enabled signal acquisition in advanced industrial automation systems. It processes 4–20 mA input signals from field transmitters and converts them into precise digital data for Honeywell Experion-based control environments.
Engineered within the Series 8 I/O platform, the 8C-PAIHA1 delivers 16-channel high-resolution input capability with integrated HART communication support. It enables real-time device diagnostics, process variable monitoring, and enhanced field asset visibility while maintaining strong signal stability in noisy industrial environments.
With built-in galvanic isolation, fast 50 ms scanning, and optional redundancy support, the 8C-PAIHA1 ensures safe and reliable operation in mission-critical applications. It integrates with TAIXA1 / TAIXB1 IOTA modules, making it suitable for scalable distributed control system architectures.
Q1: What is the main function of 8C-PAIHA1?
A1: It acquires and converts HART-enabled analog signals into digital data for control systems.
Q2: How many channels does 8C-PAIHA1 support?
A2: It supports 16 single-ended input channels.
Q3: Does 8C-PAIHA1 support redundancy?
A3: Yes, redundancy is available when paired with compatible IOTA modules.
Q4: Is HART communication supported?
A4: Yes, it fully supports HART device diagnostics and process variables.
Q5: What systems is it compatible with?
A5: It integrates with Honeywell Experion and Series 8 I/O architectures.
| Number (I/O Module - Coated) | Description |
|---|---|
| 8C-PAIH54 | High-level AI HART, Differential, 16 channels |
| 8C-TAIDA1 | AI IOTA, 9-inch standard analog input termination assembly |
| 8C-TAIDB1 | AI IOTA, redundant configuration, 12-inch |
| 8C-PAIHA1 | High-level AI HART, Single-ended, 16 channels |
| 8C-PAINA1 | High-level AI without HART, Single-ended, 16 channels |
| 8C-TAIXA1 | AI IOTA, standard 6-inch module termination |
| 8C-TAIXB1 | AI IOTA, redundant 12-inch configuration |
| 8C-PAIMA1 | Low-level AI for RTD & TC temperature input, 16 channels |
| 8C-TAIMA1 | Low-level AI IOTA, 9-inch temperature input termination |
| 8C-PAOHA1 | Analog Output module with HART, 16 channels |
| 8C-PAONA1 | Analog Output module without HART, 16 channels |
| 8C-TAOXA1 | AO IOTA, standard 6-inch termination assembly |
| 8C-TAOXB1 | AO IOTA, redundant 12-inch configuration |
| 8C-PDILA1 | Digital Input module, 24V DC, 32 channels |
| 8C-PDISA1 | Digital Input Sequence of Events module, 32 channels |
| 8C-PDIPA1 | Digital Input Pulse Accumulation module, 24V DC, 32 channels |
| 8C-TDILA1 | DI IOTA, 24V digital input termination assembly, 9-inch |
| 8C-TDILB1 | DI IOTA, redundant 12-inch digital input termination |
