Product Name: 3300 XL 8 mm Proximity Probes
Brand Name: Bently Nevada
Model Number: 330104-00-05-05-02-05
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Proximity Probes |
| Brand Name | Bently Nevada |
| Model Number | 330104-00-05-05-02-05 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
The Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe is a high-precision eddy current sensor designed for non-contact shaft vibration and position monitoring in industrial rotating machinery. Manufactured by Bently Nevada, it delivers reliable performance in both standard and hazardous environments.
Constructed with a Polyphenylene sulfide (PPS) probe tip and a robust AISI 303/304 stainless steel case, the probe ensures durability and resistance to harsh conditions. It utilizes a 75 Ω triaxial FEP-insulated cable with a ClickLoc miniature coaxial connector for stable, low-noise signal transmission. Certified with CSA, ATEX, and IECEx approvals, it is suitable for use in explosive or hazardous industrial environments.
The Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe is designed to provide accurate and reliable monitoring of rotating machinery. It performs radial shaft vibration measurement, enabling the detection of common mechanical faults such as imbalance, misalignment, and structural looseness. In addition, it supports precise shaft position monitoring, capturing both axial and radial displacement to deliver critical feedback for machinery control and protection systems.
The probe also plays a key role in condition monitoring by continuously supplying real-time data to predictive maintenance systems, allowing early fault detection and long-term trend analysis. Through its non-contact eddy current sensing technology, the Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe eliminates mechanical wear, ensuring long-term operational stability and measurement reliability.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probes |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probes |
| Part Number | 330104-00-05-05-02-05 |
| Dimensions | 20.4x22x3.7cm |
| Weight | 0.1 kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Unthreaded Length Option | 00 mm |
| Overall Case Length Option | 50 mm |
| Total Length Option | 0.5 meter (1.6 feet) |
| Connector and Cable-Type Option: | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval Option | CSA, ATEX, IECEx Approvals |
| Power Requires | -17.5 Vdc to -26 Vdc |
| Supply Sensitivity | Less than 2 mV change in output voltage per volt change in input voltage |
| Output Resistance | 50 Ω |
| Nominal Probe DC Resistance | 7.45 ± 0.50 Ω |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Probe Cable | 75Ω triaxial, fluoroethylene propylene (FEP) insulated |
| Armor (optional on both) | Flexible AISI 302 or 304 SST with FEP outer jacket |
| Connector Material | Gold-plated brass or gold plated beryllium copper |
| Probe Case Torque | 33.9 N•m (300 in•lbf) (Maximum Rated ) |
The Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe is built with a PPS probe tip and AISI 303/304 stainless steel housing, ensuring strong thermal stability and corrosion resistance. It features a 75 Ω triaxial FEP-insulated cable and 50 Ω output resistance for reliable, low-noise signal transmission, supported by precise electrical performance (7.45 ± 0.50 Ω DC resistance and <2 mV/V sensitivity).
With a 0.5 m length, 50 mm case, and high torque capacity, it offers flexible installation, while optional armored cabling enhances durability in harsh conditions. Certified with CSA, ATEX, and IECEx, it is suitable for hazardous and explosive industrial environments.
The Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe delivers exceptional accuracy and stability, ensuring precise and repeatable measurements even under fluctuating voltage and environmental conditions. Its low supply sensitivity (less than 2 mV variation per volt input change) guarantees consistent output performance. The triaxial cable design and ClickLoc connector minimize signal loss and electromagnetic interference, enhancing data reliability. Built with durable materials and optional armored protection, the probe performs efficiently in harsh industrial environments, including high temperature, vibration, and hazardous zones. It supports predictive maintenance strategies by providing reliable real-time monitoring data, ultimately improving operational efficiency and reducing downtime and maintenance costs.
Q1: Is the Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe suitable for hazardous environments?
A: Yes, the 330104-00-05-05-02-05 Proximity Probe is certified with CSA, ATEX, and IECEx approvals for use in hazardous and explosive environments.
Q2: What is the operating voltage range of the 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe?
A: The 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe operates within -17.5 Vdc to -26 Vdc.
Q3: How does the 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe ensure signal accuracy?
A: The Bently Nevada 330104-00-05-05-02-05 ensures accuracy through low supply sensitivity, triaxial shielding, and high-quality materials that minimize noise and signal loss.
Q4: What are the installation features of the 330104-00-05-05-02-05 Probe?
A: The 330104-00-05-05-02-05 offers flexible installation with a 0.5 m cable length, 50 mm case length, and a secure ClickLoc connector.
Q5: What ensures durability in the 330104-00-05-05-02-05 Proximity Probe?
A: The 330104-00-05-05-02-05 uses stainless steel construction, PPS tip material, and optional armored cabling to ensure long-term durability in harsh environments.
