Honeywell CC-PAOH51 51410070-275 Analog Output 16pt HART Original new, China Honeywell CC-PAOH51 51410070-275 Analog Output 16pt HART Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
CC-PAON01 51410070-175	CC-PAOH51 51410070-275
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Description
Product Model	CC-PAOH51 51410070-275
Brand	Honeywell
Product Type	High-Level Analog Output with HART
Output Signal Type	4–20 mA with HART
Output Channels	16 Channels
Output Ripple	<100 mV Peak-to-Peak
Output Linearity	±0.05% of Full Scale
Calibrated Accuracy	±0.35% of Full Scale
Output Temperature Drift	0.005% of Full Scale/°C
Maximum Resistive Load	800 Ohms
Maximum Output Voltage	16 V
Maximum Open Circuit Voltage	22 V
Response Time	Within 80 ms
HART Capability	Status & Configuration Support
Redundancy Support	Optional
Open Wire Detection	Supported
Compatible IOTA Models	CC-TAOX51, CC-TAOX61
Dimensions	5.5x15.8x14.5cm
Weight	0.3kg

Description

HoneywellCC-PAOH51 51410070-275is a high-performance analog output module with integrated HART communication, designed for advanced process control in Experion Series C automation systems. It provides precise 4–20 mA current signals to field actuators, control valves, and monitoring devices while enabling digital HART-based configuration and diagnostics. The module is engineered for reliable operation in continuous and safety-critical industrial environments.

TheCC-PAOH51 51410070-275supports comprehensive self-diagnostics, configurable FAILOPT safety behavior, and optional redundant architecture to enhance system availability. Compatible withCC-TAOX51andCC-TAOX61IOTA platforms, it ensures flexible deployment in both standard and redundant control system configurations within Honeywell Experion architecture.

With built-in HART communication for real-time status and configuration, along with open-wire detection and low signal ripple performance, theHoneywell CC-PAOH51delivers enhanced reliability, improved asset visibility, and stable operation across complex industrial automation applications.

Applications

Power plants: Used for turbine control, actuator positioning, and generator monitoring systems.
Substations: Supports intelligent signal communication for switchgear and protection systems.
Chemical plants: Enables automated process control with HART-enabled diagnostics and monitoring.
Oil & gas facilities: Provides reliable analog output with enhanced field device communication.
Steel mills: Performs stable control operations in high-temperature and high-interference environments.
Water treatment plants: Used for dosing control, pump regulation, and process automation systems.
Machinery manufacturing plants: Supports robotic systems, production lines, and automated packaging control.

Features

16-channel 4–20 mA analog output module
Integrated HART communication capability
Advanced self-diagnostic functions
Configurable FAILOPT per channel
Optional redundant architecture support
Open-wire detection and fault reporting
High signal accuracy and linearity
Low ripple and stable output performance
Industrial-grade safety and reliability design
Compatible with Honeywell Series C IOTA systems

Functions

Provides precise analog current output control
Enables HART-based device configuration and diagnostics
Supports actuator and valve position control
Detects field wiring faults automatically
Maintains safe-state output behavior under failure conditions
Supports distributed process automation systems
Enhances asset monitoring and system visibility
Ensures stable operation in continuous industrial processes

FAQ

Q1: What is the main function of CC-PAOH51 51410070-275?
A1: It provides 4–20 mA analog output with integrated HART communication for industrial process control.

Q2: How many channels does the CC-PAOH51 support?
A2: The module supports 16 analog output channels.

Q3: Does the CC-PAOH51 51410070-275 support HART communication?
A3: Yes, it supports HART for device status monitoring and configuration.

Q4: Which IOTA modules are compatible with this unit?
A4: It is compatible with CC-TAOX51 and CC-TAOX61 IOTA platforms.

Q5: What industries use the Honeywell CC-PAOH51?
A5: It is widely used in power generation, oil & gas, chemical processing, steel production, and manufacturing automation industries.

Spares

Model or Part Number	Describe
CC-PAOH51	Analog Output 16pt HART, 16 Channels
CC-TAOX51	AO IOTA, 6 Inch
CC-TAOX61	AO IOTA Redundant, 12 Inch
CC-PAON01	Analog Output 16pt without HART, 16 Channels
CC-TAON01	AO IOTA, 6 Inch
CC-TAON11	AO IOTA Redundant, 12 Inch
CC-PDIL01	Digital Input 24V, 32 Channels
CC-PDIS01	Digital Input Sequence of Events, 32 Channels
CC-PDIL51	Digital Input 24V, 32 Channels
CC-TDIL01	DI 24V IOTA, 9 Inch
CC-TDIL11	DI 24V IOTA Redundant, 12 Inch
CC-TDIL51	DI 24V IOTA, 9 Inch
CC-TDIL61	DI 24V IOTA Redundant, 12 Inch
CC-PDIH01	Digital Input High Voltage, 32 Channels
CC-TDI110	DI 110V IOTA, 9 Inch
CC-TDI120	DI 110V IOTA Redundant, 12 Inch
CC-TDI220	DI 220VAC IOTA, 9 Inch
CC-TDI230	DI 220VAC IOTA Redundant, 12 Inch
CC-PDOB01	Digital Output 24V Bussed Output, 32 Channels
CC-TDOB01	DO 24V Bussed IOTA, 9 Inch
CC-TDOB11	DO 24V Bussed IOTA Redundant, 12 Inch
CC-TDOR01	Digital Output Relay IOTA, 6 Inch
CC-TDOR11	Digital Output Relay IOTA Redundant, 12 Inch
CC-SDOR01	DO Relay Extension Board, 12 Channels
CC-PUIO01	Universal Input Output, 32 Channels
CC-TUIO01	Universal Input Output IOTA, 12 Inch
CC-TUIO11	Universal Input Output IOTA Redundant, 18 Inch
CC-PUIO31	Universal Input Output, 32 Channels
