Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330101-20-36-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-20-36-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330101-20-36-10-02-00 |
|
Series |
Bently Nevada 3300 XL 8 mm |
|
Probe Type |
Eddy current proximity probe |
|
Thread |
3/8-24 UNF |
|
Measurement Range |
0.25–2.3 mm linear range |
|
Cable Length |
5.0 m standard (options available) |
|
Connector Type |
ClickLoc coaxial connector |
|
Material |
Stainless steel probe body |
|
Operating Temp |
-52°C to +177°C |
|
Dimension |
1.6x1.3x113cm |
|
Weight |
0.08kg |
|
Installation Type |
Armored / non-armored options |
The 330101-20-36-10-02-00 is a high-precision proximity probe from the Bently Nevada 3300 XL 8 mm series, engineered for accurate vibration and shaft position monitoring in rotating machinery. Utilizing advanced eddy-current technology, it delivers stable, non-contact measurement performance for critical industrial assets such as turbines, compressors, and generators.
As part of the 330101 probe family and compatible with models like 330102, this system ensures full interchangeability with 3300 XL extension cables and Proximitor sensors. Its robust 3/8-24 UNF threaded design and optional armored cable structure provide strong mechanical stability and reliable installation in demanding environments.
Designed to meet API 670 standards, the 330101-20-36-10-02-00 offers excellent linear response, EMI resistance, and long-term measurement stability, making it suitable for continuous condition monitoring and machinery protection in harsh industrial operations.
Q1: What is the 330101-20-36-10-02-00 used for?
A1: It is used for vibration and shaft position measurement in rotating machinery systems.
Q2: Is it compatible with other Bently Nevada systems?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: Can it operate in harsh industrial environments?
A3: Yes, it is designed for high temperature, vibration, and EMI-intensive conditions.
Q4: Does it require recalibration when replaced?
A4: No, it supports full interchangeability without bench calibration.
Q5: Which industries commonly use this probe?
A5: It is widely used in power generation, petrochemical, steel, and manufacturing industries.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”×8”×6”, supports up to 4 Proximitor Sensors in DIN or panel mount configuration, ATEX certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13”×9.5”×7”, supports up to 8 DIN-mount or 6 panel-mount sensors, hazardous area approvals including ATEX Zone 0/1 and North American Division 1/2 |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for Proximitor sensor installation |
| 148722-01 | 3300 XL test plug with 3-pin adapter and color-coded wires for Proximitor sensor testing without removing field wiring |
| 04310310 | Panel-mount screw (6-32 UNC), required 4 pieces per Proximitor sensor, used for secure mounting |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, provides insulation and environmental protection for connectors |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes tools and protectors |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package, includes 10 pairs for environmental protection of probe and extension cable connectors |
| 03839410 | 75Ω triaxial male connector protector for extension cable-side connection protection |
| 03839420 | 75Ω triaxial female connector protector for probe and Proximitor sensor connection protection |
