Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-00-07-20-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-07-20-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Product Model |
330103-00-07-20-02-00 |
|
Type |
8 mm Eddy Current Proximity Probe |
|
Thread Type |
M10 x 1 metric thread |
|
Probe Diameter |
8 mm |
|
System Compatibility |
3300 XL Proximitor System |
|
Cable Type |
Triaxial shielded cable |
|
Measurement Range |
Up to 2 mm linear range (system dependent) |
|
Operating Temp |
-52°C to +177°C (typical system range) |
|
Dimension |
23.5x2x18cm |
|
Weight |
0.12kg |
The 330103-00-07-20-02-00 3300 XL 8 mm proximity probe is designed for precise vibration and position monitoring in industrial machinery systems. Built on the 3300 XL eddy current technology platform, it delivers stable, high-resolution measurement performance for critical rotating equipment applications such as turbines, compressors, and motors.
This probe features an M10 x 1 threaded housing and supports flexible configuration options in unthreaded length, overall case length, and cable termination types. It is engineered for reliable signal transmission when paired with 3300 XL extension cables and Proximitor sensors, ensuring consistent output stability even in harsh operating environments.
With strong EMI/RFI resistance and robust mechanical construction, the 330103-00-07-20-02-00 ensures long service life, interchangeability, and compliance with industrial monitoring standards, making it suitable for high-demand predictive maintenance systems.
Q1: What is the 330103-00-07-20-02-00 used for?
A1: It is used for vibration and position monitoring in rotating machinery such as turbines, motors, and compressors.
Q2: Is this probe compatible with the 3300 XL system?
A2: Yes, it is fully compatible with the 3300 XL Proximitor sensor and extension cable system.
Q3: What type of measurement does this probe provide?
A3: It provides non-contact eddy current measurement for vibration and shaft position.
Q4: Can it operate in harsh industrial environments?
A4: Yes, it is designed for high EMI, high temperature, and heavy-duty industrial conditions.
Q5: Does it support interchangeable components?
A5: Yes, it supports full interchangeability with other 3300 XL probe system components.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing 12”x12”x6”, supports up to 8 Proximitor Sensors in DIN-mount or 6 in panel-mount configuration, available with ATEX Zone 0 and Zone 1 certifications |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing 12”x8”x6”, supports up to 4 Proximitor Sensors in DIN or panel mount configuration, ATEX Zone 0 and Zone 1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing 13”x9.5”x7”, supports up to 8 Proximitor Sensors (DIN-mount) or 6 (panel-mount), suitable for hazardous area installations, ATEX Zone 0/1 and North American Division 1/2 approved |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, customizable length |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3 test pins, color-coded 1-meter wires terminated in banana plugs, used for Proximitor sensor testing without removing field wiring |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming screw, four required per sensor |
| 03200006 | Silicone self-fusing tape roll (9.1 m / 10 yd) for connector protection and environmental insulation |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes installation tools |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for environmental sealing of probe-to-extension cable connection |
| 03839420 | 75Ω triaxial female connector protector for probe lead and extension cable protection, also used for Proximitor sensor connection shielding |
