Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-05-15-05-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-05-15-05-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330103-05-15-05-02-00 |
|
Type |
3300 XL 8 mm Proximity Probe |
|
Thread |
M10 x 1 |
|
Unthreaded Length |
Configurable (10 mm increments) |
|
Total Cable Length |
1.5 m (typical configuration option) |
|
Probe Diameter |
8 mm |
|
Output Type |
Eddy current analog signal |
|
Operating Temperature |
-52°C to +177°C |
|
Weight |
0.08kg |
|
Material |
Stainless steel probe case |
|
System Compatibility |
3300 XL Proximitor + extension cable |
|
Dimension |
23x1.6x20.5cm |
The 330103-05-15-05-02-00 proximity probe is part of the advanced eddy current monitoring range developed by Bently Nevada. Designed for high-precision shaft vibration and position measurement, it delivers stable performance in critical rotating machinery environments such as turbines, compressors, and generators.
The 330103-05-15-05-02-00 features an 8 mm probe architecture with robust M10 x 1 threading, ensuring reliable installation even under mechanical stress and high-temperature conditions. It operates as part of a three-component system (probe, extension cable, and Proximitor sensor) to provide accurate dynamic and static signal output.
Engineered for interchangeability and long-term stability, the 330103-05-15-05-02-00 supports industrial monitoring systems requiring high accuracy, EMI resistance, and compliance with API 670 standards for machinery protection.
Q1: What is the 330103-05-15-05-02-00 used for?
A1: It is used for measuring shaft vibration and position in rotating industrial machinery systems.
Q2: Is the 330103-05-15-05-02-00 compatible with 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL extension cables and Proximitor sensors.
Q3: What industries use this proximity probe?
A3: It is widely used in power plants, petrochemical plants, steel mills, and manufacturing automation systems.
Q4: What is the operating temperature range?
A4: It operates reliably from -52°C to +177°C depending on system configuration.
Q5: Does it support high vibration environments?
A5: Yes, it is designed for high-stability performance in harsh vibration and EMI-heavy industrial environments.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual for installation, configuration, and maintenance guidance. |
| 175751 | 3300 XL multi-purpose stainless steel housing (12”×12”×6”), supports up to 8 DIN-mounted or 6 panel-mounted Proximitor sensors, ATEX Zone 0/1 certified option available. |
| 176467 | Compact 3300 XL stainless steel housing (12”×8”×6”), designed for up to 4 Proximitor sensors in DIN or panel mount configuration with ATEX Zone 0/1 approval. |
| 330181 | Heavy-duty 3300 XL stainless steel housing (13”×9.5”×7”), supports up to 8 DIN-mounted or 6 panel-mounted sensors, suitable for hazardous area installations with ATEX and North American certifications. |
| 02120015 | Bulk field wire: 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, supplied in custom cut lengths for industrial signal wiring. |
| 138492-01 | Replacement panel-mount mounting pad for securing 3300 XL Proximitor Sensor in panel installation configurations. |
| 138493-01 | Replacement DIN-mount mounting pad designed for secure DIN rail installation of 3300 XL Proximitor Sensors. |
| 148722-01 | 3300 XL test plug used to verify Proximitor sensor performance without removing field wiring, compatible with terminal strip test pin access. |
| 04310310 | 6-32 UNC panel-mount screw for 3300 XL Proximitor Sensor installation; four screws required per sensor (typically supplied with housing). |
| 03200006 | Silicone self-fusing tape (9.1 m roll) used for connector insulation and environmental protection in field installations. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes installation tools and protective accessories. |
| 136536-01 | Connector protector adapter allowing compatibility between pre-1998 installation tools and modern 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors (10 pairs) designed for environmental sealing of probe and extension cable connections in harsh industrial conditions. |
| 03839410 | 75Ω triaxial male connector protector for extension cable side, ensuring secure environmental sealing of signal connections. |
| 03839420 | 75Ω triaxial female connector protector for probe or extension side, providing environmental protection and contamination resistance for connectors. |
