Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-06-13-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-06-13-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Product Model |
330103-06-13-10-02-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 metric thread |
|
Probe Type |
Eddy current non-contact sensor |
|
Cable Type |
75Ω triaxial shielded cable |
|
Length Options |
0.5 m to 9.0 m configurable |
|
Output Signal |
Proportional DC voltage |
|
Unthreaded Length Option |
60 mm |
|
Weight |
0.08kg |
|
Dimension |
1.8x1.5x119cm |
|
Overall Case Length Option |
130mm |
|
Total Length Option |
1.0 meter (3.3 feet) |
|
Connector and Cable-Type Option |
Miniature coaxial ClickLoc connector, standard cable |
|
Agency Approval Option |
Not required |
The 330103-06-13-10-02-00 proximity probe is part of the advanced 3300 XL 8 mm eddy current monitoring series developed for high-precision machinery protection. Designed for compatibility with the 3300 XL Proximity Transducer System, it delivers stable, non-contact measurement of shaft vibration and position in rotating equipment environments.
This model, including variants such as 330103 and 330104, supports metric M10 x 1 threading and is available in armored or non-armored configurations. It works seamlessly with extension cables and Proximitor sensors to form a fully interchangeable measurement chain without requiring individual calibration.
Engineered for industrial reliability, the system is widely used in turbines, compressors, and critical rotating assets. Its robust construction ensures consistent signal output even under high temperature, vibration, and electromagnetic interference conditions.
Q1: What is the 330103-06-13-10-02-00 used for?
A1: It is used for measuring shaft vibration and position in rotating machinery such as turbines and compressors.
Q2: Is the probe compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: What type of measurement does it provide?
A3: It provides non-contact eddy current displacement measurement with analog voltage output.
Q4: Can it operate in harsh industrial environments?
A4: Yes, it is designed for high temperature, vibration, and EMI-prone conditions.
Q5: Does it require calibration during installation?
A5: No, the system supports interchangeability without bench calibration.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual for installation, operation, and maintenance reference |
| 175751 | Multi-purpose stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors with hazardous area certification options |
| 176467 | Compact stainless steel housing, 12”×8”×6”, supports up to 4 3300 XL Proximitor Sensors in DIN-mount or panel-mount configurations |
| 330181 | Stainless steel hazardous-area housing, 13”×9.5”×7”, designed for up to 8 DIN-mount or 6 panel-mount Proximitor Sensors |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, custom length available |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL Proximitor Sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for DIN rail Proximitor Sensor mounting applications |
| 148722-01 | 3300 XL test plug with color-coded banana plug leads for Proximitor Sensor signal testing and diagnostics |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor installation, 6-32 UNC thread forming type |
| 03200006 | Silicone self-fusing protective tape roll for connector insulation and environmental sealing protection |
