Product Name: 3300 XL 8 mm Proximity Probe
Brand Name: Bently Nevada
Model Number: 330104-00-15-05-02-00
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330104-00-15-05-02-00 3300 XL 8 mm Proximity Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Part Number | 330104-00-15-05-02-00 |
| Estimated shipping dimensions | 1.8x1.8x60cm |
| Weight | 0.12kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Probe sealing material | Viton® O ring. |
| Probe Case Material | AISI 303 or 304 stainless steel (SST). |
| Probe Tip Material | Polyphenylene sulfide (PPS). |
| Minimum unthreaded length | 0 mm |
| Overall Case Length Option | 150 mm |
| Total Length Option | 0.5 meter (1.6 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval Option | Not required |
| Nominal Probe DC Resistance | 7.45 ± 0.50 Ω |
The Bently Nevada 330104-00-15-05-02-00 is part of the 3300 XL 8 mm proximity probe series designed for industrial machinery monitoring applications. It features a robust M10 × 1 threaded and armored construction, with a compact design suitable for installation in confined or demanding mechanical environments. The probe is built with high-quality materials, including AISI 303/304 stainless steel for the case and PPS (polyphenylene sulfide) for the probe tip, ensuring durability and resistance to harsh industrial conditions.
This model incorporates a 0.5-meter miniature coaxial ClickLoc connector standard cable and Viton® O-ring sealing, providing reliable environmental protection and stable electrical performance. The design includes a minimum unthreaded length of 0 mm and an overall case length of 150 mm, making it flexible for a wide range of mounting configurations. Its construction emphasizes mechanical strength and long-term operational stability.
The primary function of the 330104-00-15-05-02-00 proximity probe is to measure the distance between the probe tip and a conductive target in rotating machinery. It operates as part of a proximity sensing system that converts physical displacement into an electrical signal, enabling precise monitoring of both static shaft position and dynamic vibration behavior. This makes it essential for condition monitoring and predictive maintenance applications.
When integrated with a 3300 XL extension cable and Proximitor sensor, the probe produces a voltage output proportional to the measured gap distance. This signal can be used to track machine vibration, detect imbalance or misalignment, and monitor shaft movement in real time. It also supports Keyphasor signal acquisition for accurate rotational speed and phase reference measurement.
The Bently Nevada 330104-00-15-05-02-00 probe is widely used in industrial machinery condition monitoring and protection systems, including:
Typical use cases include:
The 330104-00-15-05-02-00 is fully compatible with the complete Bently Nevada 3300 XL 8 mm proximity transducer system, including:
The probe is also backward compatible with legacy non-XL 5 mm and 8 mm probe systems, allowing seamless upgrades and component replacement without additional calibration requirements. Its interchangeable design simplifies maintenance and minimizes system downtime.
